        8CX300Nd/N Coaxial Woofer

        Beyma 8CX300Nd/N Coaxial Woofer

        €399,95

        2 In stock

        Add to cart

        Beyma 8CX300Nd/N Coaxial Woofer

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Beyma
        Show all New products
        8" | 8 Ω
        8CX300Nd/N Coaxial Woofer
        8CX300Nd/N Coaxial Woofer
        8CX300Nd/N Coaxial Woofer
        8CX300Nd/N Coaxial Woofer
        € 330,54€ 399,95 2 In stock
        • -5% Purchase 4 for only € 379,95 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped tomorrow
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        8CX300Nd/N Coaxial Woofer
        8CX300Nd/N Coaxial Woofer
        8CX300Nd/N Coaxial Woofer
        8CX300Nd/N Coaxial Woofer

        Product description Beyma 8CX300Nd/N Coaxial Woofer

        Premium 8-inch coaxial transducer featuring a neodymium magnet system, engineered for compact full-range enclosures that demand clarity, efficiency, and natural sound reproduction.



        Highlights of the Beyma 8CX300Nd/N

        • 500 W / 100 W program power (LF / HF) with 96 / 104 dB sensitivity
        • 2.5” / 1.75” voice coils for LF/HF with shared lightweight neodymium magnet
        • Weatherproof carbon fiber-loaded paper cone and Santoprene™ surround
        • Wide frequency range: 60 – 20,000 Hz with shorting cap and PM4 diaphragm for extended, low-distortion response



        Product details Beyma 8CX300Nd/N

        Beyma 8CX300Nd/N Coaxial Transducer



        The Beyma 8CX300Nd/N is a high-performance 8” coaxial transducer designed to deliver full-range sound in a single point source format. With 250 W AES / 500 W program power in the LF section and 50 W AES / 100 W program power in the HF driver, this unit ensures a balanced and powerful acoustic output. The 96 dB (LF) and 104 dB (HF) sensitivities contribute to its impressive efficiency and clarity. The transducer features a 2.5” LF voice coil and a 1.75” HF voice coil, both mounted on a common, lightweight neodymium magnet structure for optimal alignment and space efficiency. A shorting cap minimizes harmonic distortion and extends the upper frequency range, while the PM4 diaphragm in the HF driver promotes natural and smooth sound reproduction. Its cone is constructed from carbon fiber-loaded paper and is treated for waterproofing, supported by a Santoprene™ surround for mechanical control and environmental durability. With a usable frequency range from 60 Hz to 20 kHz and a recommended HF crossover of 1.5 kHz (12 dB/oct min), the 8CX300Nd/N is suited for high-quality applications such as studio monitors, compact PA systems, and single-source reinforcement in fixed or portable setups. Its compact depth (106 mm) and 2.8 kg weight make it ideal for space-conscious designs where fidelity and output are non-negotiable.

        Show more

        Specifications

        Article number
        8CX300Nd/N
        EAN
        8435469041844
        Woofer Type
        Coaxial Transducer
        Nominal Diameter
        Woofer 8", Tweeter 1.75"
        Power Handling (RMS)
        500 Watts
        Continuous Program Power
        Woofer 600 Watts, Tweeter 100 Watts
        Impedance (Z)
        Woofer 8 Ω, Tweeter 8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        96 dB
        Frequency Response
        60-20.000 Hz
        Voice Coil Diameter
        Woofer 2.5", Tweeter 1.75"
        DC Resistance (Re)
        5.4 Ω
        Voice Coil Inductance (Le)
        0,3 mH
        Resonant Frequency (Fs)
        61 Hz
        Mechanical Q (Qms)
        13
        Electromagnetic Q (Qes)
        0.30
        Total Q (Qts)
        0.29
        Diaphragm Mass Inc. Airload (Mms)
        0,020 kg
        Mechanical Compliance of Suspension (Cms)
        335 µm / N
        Surface Area of Cone (Sd)
        0,022 m²
        Volume of Displacement (Vd)
        132 cm³
        BL Product (BL)
        12 N/A
        Compliance Equivalent Volume (Vas)
        23 Liters
        Maximum Linear Excursion (Xmax)
        6 mm
        Driver's Mechanical Losses (Rms)
        0,6 kg / s
        Magnet Material
        Neodymium
        Overall Outside Diameter
        212 mm
        Overall Depth
        106 mm
        Baffle Cutout Diameter
        180 mm
        # Mounting Holes
        8
        Mounting Hole Diameter
        5 mm

        Show more

        Reviews

        1 reviews
        Review this product
        5 of 5
        Wie immer, alles prima. Große Auswahl für High End Projekte, faire Preise, unkomplizierte Abwicklung und schnelle, zuverlässige Lieferung. Weiter so!
        By Thomas on 29 December 2025
