        • Designed for woofer applications and optimized for small bass-reflex cabinets

        Product description Beyma 10G40 Bass-midwoofer

        The Beyma 10G40 is a robust 10” low-frequency transducer built for clean bass reproduction in compact reflex enclosures. With a 3” copper voice coil and high mechanical compliance, it offers solid performance for professional woofer applications.



        Highlights of the Beyma 10G40

        • 400 W AES / 800 W program power with 95 dB sensitivity
        • 3” copper voice coil on polymide fiberglass former
        • ±7 mm Xmax and 28 mm peak-to-peak excursion for controlled bass output
        • Optimized for small bass-reflex cabinets (20–70 liters)



        Product details Beyma 10G40

        Beyma 10G40 Low Frequency Transducer



        The Beyma 10G40 is a 10-inch woofer from the G40 Series, designed for efficient low-frequency reproduction in compact enclosure designs. With a power handling capacity of 400 W AES and 800 W program power, it delivers a consistent and powerful response while maintaining a sensitivity of 95 dB (1W/1m). The transducer features a 3” copper voice coil wound on a polymide fiberglass former and housed within a large magnetic structure for optimal heat dissipation. With an extended Xmax of ±7 mm and peak-to-peak excursion up to 28 mm, it ensures clean and punchy bass even at high drive levels. Operating from 45 Hz to 4,000 Hz, the 10G40 is ideal for woofer applications in small reflex enclosures (recommended 20 to 70 liters). With a net weight of 5.7 kg and a shallow depth of 118 mm, it provides ease of integration into compact, portable speaker systems without compromising performance.

        Show more

        Specifications

        Article number
        10G40
        EAN
        8435469042353
        Woofer Series
        Beyma G40 series
        Woofer Type
        Low Frequency Transducer
        Nominal Diameter
        10"
        Power Handling (RMS)
        400 Watts
        Continuous Program Power
        800 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        95 dB
        Frequency Response
        45-4.000 Hz
        Voice Coil Diameter
        3"
        DC Resistance (Re)
        6.2 Ω
        Voice Coil Inductance (Le)
        0.6 mH
        Resonant Frequency (Fs)
        45 Hz
        Mechanical Q (Qms)
        7.1
        Electromagnetic Q (Qes)
        0.32
        Total Q (Qts)
        0.30
        Diaphragm Mass Inc. Airload (Mms)
        0,052 kg
        Mechanical Compliance of Suspension (Cms)
        241 µm / N
        Surface Area of Cone (Sd)
        0,038 m²
        Volume of Displacement (Vd)
        266 cm³
        BL Product (BL)
        17 N/A
        Compliance Equivalent Volume (Vas)
        49 Liters
        Maximum Linear Excursion (Xmax)
        +/- 7 mm
        Driver's Mechanical Losses (Rms)
        2,1 kg / s
        Voice Coil Former
        Copper
        Overall Outside Diameter
        260.5 mm
        Overall Depth
        118 mm
        Baffle Cutout Diameter
        228 mm
        Bolt Circle Diameter
        243.5 mm
