Arylic Up2Stream amp 2.0 WiFi and Bluetooth 5.0 Stereo Amplifier Board

Delivery time: 1-4 business days

  • Article code: Up2Stream Amp 2.0
  • Stock: >10 In stock

Does your next project require a high-end amplifier, Bluetooth 5.0 connection, Wi-Fi streaming, multi-room use, or maybe even all of them? Then boy, do I have news for you! The brand new Up2Stream Amp is here to satisfy all your needs!

€ 79,95 Incl. 21% VAT

  • Buy 4 for €75,95 each and save 5% Sale 5%

Add to wishlist

  • Low international shipping rates Tooltip

    Find all shipping rates and free shipping thresholds here

  • Same day shipping
  • 45-day money back guarantee
  • International payment options

Product description

Arylic Up2Stream amp 2.0 WiFi and Bluetooth 5.0 Stereo Amplifier Board

Does your next project require a high-end amplifier, Bluetooth 5.0 connection, Wi-Fi streaming, multi-room use or maybe even all of them? Then boy, do I have news for you! The brand new Up2Stream Amp is here to satisfy all your needs!



Highlights

  • Wireless streamer and amplifier in one
  • Bluetooth 5.0 and Wi-Fi streaming using the free app
  • Supports multi-room use.



Product Details

Arylic Up2Stream amp 2.0 WiFi and Bluetooth 5.0 Stereo Amplifier Board



Does your next project require a high-end amplifier, Bluetooth 5.0 connection, Wi-Fi streaming, multi-room use, or maybe even all of them? Boy, do I have good news for you! The brand new Up2Stream Amp is here to satisfy all your needs!



This amplifier can stream music off of any reputable streaming service using its free Android and iOS app; Wi-Fi, Bluetooth 5.0, DLNA, AirPlay, Spotify, Deezer, Tidal, Qobuz, iheartRadio, Napster, internet radio you name it. Not only is the app very useful for uncompressed music streaming, but it also allows you to change the name of every Arylic product on your network and to set up a multi-room sound system.



The amplifier uses a powerful low distortion class D amplifier chip outputting up to 50 Watts per channel into 4 Ohms. It features every connection one may need and even has a USB port that can either be used as a USB DAC or for USB storage of your favorite tracks.



To control the amplifier, the free app, a PC or the optional remote control can be used.



Warning: Up2Stream Amp 2.0 must use 12V-26 VDC input, higher voltage power supply may damage the board.

Specifications

Specifications for: Up2Stream amp 2.0 WiFi and Bluetooth 5.0 Stereo Amplifier Board

  • Rated power output (RMS) The electrical power measured in watts (W) that an amplifier can output per channel, without damaging the amplifier or the output signal is çlipped'. RMS = Root Mean Square. 2 x 50 watts at 4 ohms (21 V)
  • Bridged power output (RMS) The electrical power expressed in watts (W) that an amplifier can output per bridged channel (2 x stereo to 1 x mono output), without damaging the amplifier or the output signal is çlipped'. RMS = Root Mean Squeare. -
  • Minimum load Shows the minimum load that an amplifier can control in ohms. A lower impedance of a speaker is not recommended if it is lower than the minimum impedance of an amplifier. An amplifier works best when the impedance of the speaker falss within the impedance range that the amplifier prescribes (for example, 4 to 8 ohms). 4 Ohms
  • Signal-to-noise ratio (SNR) Shows the strength level of signal power compares to a level of noise power. Generally, higher values ​​means better specification. 91 dB
  • Distortion SPEC Distortion 0.03 % THD at 1 kHz, 50 Watts
  • View all specifications
  • Distortion bridged -
  • Efficiency -
  • Frequency response 20 - 20,000 Hz
  • Input impedance -
  • Input sensitivity -
  • Auto turn-on sensitivity -
  • DSP -
  • DAC micro-USB DAC
  • Maximum sampling rate up to 24bit, 192kHZ
  • Circuit Topology -
  • Amplifier classification Class D
  • Speaker output channels Left and Right
  • Subwoofer output channel -
  • Analog in/out 2/1
  • Optical S/PDIF in/out -
  • Coaxial in/out -
  • RCA in/out -
  • AUX in/out -
  • Bus in/out -
  • XLR in/out -
  • USB USB power, USB DAC, USB storage
  • Memory card slot -
  • Network connection Single 10/100M RJ45
  • Headphone jack -
  • Subwoofer pre-out -
  • Bluetooth Bluetooth 5.0
  • NFC -
  • Wi-Fi IEEE802.11 b/g/n 2.4G
  • Banana plug compatible -
  • Remote control IR remote compatible
  • App control Free Android and iOS app
  • Auto turn-on -
  • Accepted file formats FLAC, MP3, AAC, AAC+, ALAC, APE, WAVE
  • Equalizer (EQ) adjustment in-app equalizer adjustment
  • Equalizer (EQ) profiles -
  • Multi zone/room App supports Multi-Room playback
  • Crossover frequency adjustment -
  • Bridge mode -
  • Power requirements DC 12V-26V 4A
  • Power inlet connector 5.5 mm x 2.1 mm DC plug
  • Power consumption
  • Stand-by power consumption -
  • Dimensions (D x W x H) 80 x 100 x 20 mm
  • Case material
