        C220-6-222 Bass-midwoofer

        Accuton C220-6-222 Bass-midwoofer

        €1.399,95

        Out of stock

        Add to cart

        Accuton C220-6-222 Bass-midwoofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Accuton
        Show all Bass-mid woofer
        8
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        € 1.156,98€ 1.399,95 Out of stock
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer
        C220-6-222 Bass-midwoofer

        Product description Accuton C220-6-222 Bass-midwoofer

        The Accuton C220-6-222 is an excellent bass-midrange driver that offers a combination of exceptional performance, reliability, and build quality. It is well-suited for use in a wide variety of high-end audio applications, and is sure to please even the most discerning listener.



        Highlights

        • High-resolution ceramic sandwich cone
        • Oversized underhung 120mm Neodymium magnet system
        • Large-sized 55mm titanium voice coil former
        • Soft rubber surround



        Product Details

        Accuton C220-6-222 Bass-midwoofer


        The Accuton C220-6-222 is a high-performance bass-midrange driver that is designed for use in high-end audio applications. It features an ultra-stiff ceramic-sandwich cone, an FEA-optimized overhung motor design, and a large-sized voice coil with a 55mm titanium voice coil former. The driver also features a 38mm titanium voice coil former, a 120mm Neodymium magnet system, and a soft high-shape rubber surround. With its excellent transient response, low distortion, and wide frequency range, the Accuton C220-6-222 is the perfect choice for 2-way and 3-way loudspeakers that require high clarity and resolution.

        Show more

        Specifications

        Article number
        C220-6-222
        EAN
        9502545663111
        Woofer Type
        Bass-Midwoofer
        Nominal Diameter
        8.5''
        Power Handling (RMS)
        150 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        93 dB
        Frequency Response
        32 - 2.000 Hz
        Voice Coil Diameter
        55 mm
        DC Resistance (Re)
        6.7 Ω
        Voice Coil Inductance (Le)
        0.42 mH
        Resonant Frequency (Fs)
        24 Hz
        Mechanical Q (Qms)
        4.4
        Electromagnetic Q (Qes)
        0.20
        Total Q (Qts)
        0.19
        Diaphragm Mass Inc. Airload (Mms)
        27 g
        Mechanical Compliance of Suspension (Cms)
        1.95 mm/N
        Surface Area of Cone (Sd)
        224 cm²
        BL Product (BL)
        11.5 N/A
        Compliance Equivalent Volume (Vas)
        115 Liters
        Maximum Linear Excursion (Xmax)
        +/- 5 mm
        Driver's Mechanical Losses (Rms)
        0.89 kg x s
        Voice Coil Wire Material
        Copper
        Voice Coil Former
        Titanium
        Overall Outside Diameter
        220 mm
        Overall Depth
        99 mm
        Baffle Cutout Diameter
        190.50 mm
        # Mounting Holes
        6
        Mounting Hole Diameter
        4.5 mm

        Show more
