        PTT6.5PR-NF1-01 Passive Radiator

        PURIFI PTT6.5PR-NF1-01 Passive Radiator

        €129,95

        8 In stock

        PURIFI PTT6.5PR-NF1-01 Passive Radiator

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: PURIFI
        € 107,40€ 129,95 8 In stock
        • -10% Purchase 4 for only € 116,96 per piece
        • -15% Purchase 6 for only € 110,46 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description PURIFI PTT6.5PR-NF1-01 Passive Radiator

        The PTT6.5PR-NF1-01 is a 6.5” high-performance passive radiator featuring PURIFI ' s research-based technologies, including the Natural Surround and a cone made from a proprietary fiber mix.



        Highlights

        • A whole new take on passive radiator design
        • PURIFI ’s Natural Surround
        • Bimax spider
        • Engineered and manufactured in Denmark
        • High linear excursion limit
        • Tunable mass



        Product Details

        PURIFI PTT6.5PR-NF1-01 passive radiator



        PURIFI is a fresh company that designs and manufactures extremely high-performance transducers and amplifier modules. Don’t let the freshness fool you; Their leadership team consists out of some well-respected audio technology pioneers. PURIFI developed a deep understanding of many performances degrading aspects for both amplifiers and transducers. Thanks to this understanding the passive radiators from PURIFI are the most high-end passive radiators available at SoundImports.



        The challenge

        Loudspeaker drivers are known to add a large, if not the largest, amount of distortion on an audio signal chain. Reducing this distortion is a challenge with the complication of fine-tuning to improve one part (e.g. harmonic distortion) often results in a degradation of another part (e.g. intermodulation distortion). These distortions consist out of several separate distortion mechanisms. By carefully mapping and completely understanding these mechanisms, PURIFI succeeded in improving the overall performance by a large degree.



        A whole new take on passive radiator design

        PURIFI developed mathematical models for the suspension, cone, and surround. These models allowed for the optimization of different distortion mechanisms separately. The result makes that the PTT6.5PR-NF1-01 is a perfect passive radiator to accompany the PTT6.5W04 and PTT6.5W08 long-stroke bass-midwoofers.



        The mechanism

        Improvement

        Low surround radiation distortion

        Reduces harmonic and intermodulation distortion caused by surround



        FAQ

        Q: Why is this surround odd shaped?

        A: This is the PURIFI Natural Surround. Conventional surrounds create distortion as they deform. The shape of the Natural Surround reduces cone edge resonances and distortion. It might be odd looking, but form follows function here. A more detailed look shows that the surround actually represents a complex sound wave. We are told that the Natural Surround is also called ‘wormy’ by insiders.

        Show more

        Specifications

        Article number
        PTT6.5PR-NF1-01
        EAN
        0691046950055
        Woofer Series
        -
        Woofer Type
        Passive radiator
        Nominal Diameter
        6.5"
        Power Handling (RMS)
        -
        Power Handling (max)
        -
        Continuous Program Power
        -
        Impedance (Z)
        -
        Sensitivity (SPL at 1m / 2.83V)
        0 dB
        Frequency Response
        -
        Voice Coil Diameter
        -
        Magnet Weight
        -
        DC Resistance (Re)
        -
        Voice Coil Inductance (Le)
        -
        Resonant Frequency (Fs)
        17 Hz
        Mechanical Q (Qms)
        10.9
        Electromagnetic Q (Qes)
        -
        Diaphragm Mass Inc. Airload (Mms)
        80g
        Moving Mass Of Diaphragm (Mmd)
        -
        Mechanical Compliance of Suspension (Cms)
        1.05 mm/N
        Surface Area of Cone (Sd)
        133 cm²
        Volume of Displacement (Vd)
        199.5 cm³
        BL Product (BL)
        -
        Compliance Equivalent Volume (Vas)
        26.2 liter
        Maximum Linear Excursion (Xmax)
        15 mm
        Driver's Mechanical Losses (Rms)
        -
        Cone / Diaphragm Material
        Proprietary Fibre Mix
        Surround Material
        Nitrile rubber
        Voice Coil Wire Material
        -
        Voice Coil Former
        -
        Dual Voice Coil
        -
        Basket / Frame Material
        Aluminum alloy diecast
        Magnet Material
        -
        Shielded
        -
        Overall Outside Diameter
        176 mm
        Overall Depth
        48.7 mm
        Baffle Cutout Diameter
        144 mm
        Bolt Circle Diameter
        166 mm
        # Mounting Holes
        6
        Mounting Hole Diameter
        5.1 mm
        Sealed Volume
        -
        Sealed F3
        -
        Vented Volume
        -
        Vented F3
        -

        Show more
