- Article number
- SA-100
- Rated power output (RMS)
- <p>2 x 25 watts at 4 ohms<br />2 x 20 watts at 8 ohms</p>
- Bridged power output (RMS)
- -
- Minimum load
- 4 ohms
- Signal-to-noise ratio (SNR)
- > 70 dB
- Distortion
- -
- Distortion bridged
- -
- Efficiency
- -
- Frequency response
- 20 - 20,000 Hz
- Input impedance
- 46k ohms (PC/CD/aux) 12k ohms, 32k ohms (player)
- Input sensitivity
- 140 mV (PC/CD/aux) 140 mV, 25 mV (player)
- Auto turn-on sensitivity
- -
- DSP
- -
- DAC
- -
- Maximum sampling rate
- -
- Circuit Topology
- -
- Amplifier classification
- Class B
- Speaker output channels
- 2
- Subwoofer output channel
- -
- Analog in/out
- -/-
- Optical S/PDIF in/out
- -/-
- Coaxial in/out
- -/-
- RCA in/out
- 3/-
- AUX in/out
- 2/-
- Bus in/out
- -/-
- XLR in/out
- -/-
- USB
- check only charging
- Memory card slot
- -
- Network connection
- -
- Headphone jack
- check 6.3 mm
- Subwoofer pre-out
- -
- Bluetooth
- -
- NFC
- -
- Wi-Fi
- -
- Banana plug compatible
- -
- Remote control
- -
- App control
- -
- Auto turn-on
- -
- Accepted file formats
- -
- Equalizer (EQ) adjustment
- check
- Equalizer (EQ) profiles
- -
- Multi zone/room
- -
- Crossover frequency adjustment
- -
- Bridge mode
- -
- Power requirements
- 230 VAC, 50 Hz
- Power inlet connector
- -
- Power consumption
- 150 VA
- Stand-by power consumption
- -
- Dimensions (D x W x H)
- 250 x 212 x 56 mm
- Case material
- Metal
