        FR89EX 3" Neodymium Full Range Speaker

        Fountek FR89EX 3" Neodymium Full Range Speaker

        €99,95

        Out of stock

        Add to cart

        Fountek FR89EX 3" Neodymium Full Range Speaker

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Fountek
        Show all Full-range woofer
        3" | 8 Ω
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        € 82,60€ 99,95 Out of stock
        • -5% Purchase 4 for only € 94,95 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker
        FR89EX 3" Neodymium Full Range Speaker

        Product description Fountek FR89EX-8 Full-range Woofer

        Fountek’s FR89EX full range driver features an attractive black anodized aluminum cone, robust cast-aluminum frame, and an optimized long-excursion neodymium motor, for low distortion and excellent detail.



        Highlights

        • Smooth, extended frequency response from 70 to 20,000 Hz
        • High-excursion design with 5 mm of Xmax
        • Neodymium motor with underhung voicecoil design
        • Black anodized-aluminum diaphragm
        • Cast aluminum frame



        Product details

        Fountek FR89EX 3" Neodymium Full Range Speaker Driver



        Fountek has applied much of what it has learned from designing industry-leading ribbon transducers in creating its line of full-range drivers. These high-performing cone drivers feature thin-foil aluminum diaphragms that shed resonance rapidly, for exceptional detail and smooth frequency response.

        The 3" FR89EX model features a high-strength neodymium motor structure with underhung geometry, for low distortion, extended excursion, and excellent transient response. It’s a great choice for compact projects that demand the very best performance from a small full-range driver.

        Show more

        Specifications

        Article number
        FR89EX-8
        EAN
        0848864004198
        Woofer Type
        Full-range
        Nominal Diameter
        3"
        Power Handling (RMS)
        25 Watts
        Power Handling (max)
        50 Watts
        Impedance (Z)
        8 ohms
        Sensitivity (SPL at 1m / 2.83V)
        83.6 dB
        Frequency Response
        70 to 20,000 Hz
        Voice Coil Diameter
        1"
        DC Resistance (Re)
        5.7 ohms
        Resonant Frequency (Fs)
        97 Hz
        Mechanical Q (Qms)
        1.64
        Electromagnetic Q (Qes)
        0.65
        Total Q (Qts)
        0.47
        Diaphragm Mass Inc. Airload (Mms)
        2.61g
        Mechanical Compliance of Suspension (Cms)
        0.99 mm/N
        Surface Area of Cone (Sd)
        27.34 cm²
        BL Product (BL)
        3.78 Tm
        Compliance Equivalent Volume (Vas)
        0.04 ft.³
        Maximum Linear Excursion (Xmax)
        5 mm
        Cone / Diaphragm Material
        Aluminum
        Surround Material
        Polyurethane
        Voice Coil Wire Material
        Copper
        Voice Coil Former
        Aluminum
        Basket / Frame Material
        Cast Aluminum
        Magnet Material
        Neodymium
        Overall Outside Diameter
        3.48"
        Overall Depth
        1.68"
        Baffle Cutout Diameter
        2.87"
        # Mounting Holes
        4
        Sealed Volume
        0.02 ft.³
        Sealed F3
        166Hz
        Vented Volume
        0.05 ft.³
        Vented F3
        82 Hz

        Show more
