    Fountek FR88EX 3" Full Range Speaker

    € 36,95 Out of stock: delivery time is 1 week
    Fountek’s FR88EX full range driver features an attractive thin-foil aluminum cone, robust cast-aluminum frame, and an optimized high-strength neodymium motor, for low distortion and excellent detail.... Show more
    Bulk discount Enjoy these awesome discount deals
    • -5% Order 4 for only €35,10 per piece
    • Low international shipping rates
    • Same day shipping*
    • Pay with PayPal, Creditcard, and more
    • In-house technical support

    Product description

    Fountek’s FR88EX full range driver features an attractive thin-foil aluminum cone, robust cast-aluminum frame, and an optimized high-strength neodymium motor, for low distortion and excellent detail.



    Highlights

    • Attractive thin-foil aluminum diaphragm
    • Strong neodymium motor
    • High-excursion design
    • Smooth, extended frequency response
    • Cast aluminum frame



    Product details

    Fountek FR88EX 3" Neodymium Full Range Speaker



    Fountek has applied much of what it has learned from designing industry-leading ribbon transducers in creating its line of full-range drivers. These high-performing cone drivers feature thin-foil aluminum diaphragms that shed resonance rapidly, for exceptional detail and smooth frequency response.



    The FR88EX model features a high-strength neodymium motor structure for low distortion, extended excursion, and excellent transient response. Its advanced design makes it a true high-end contender in small full-range drivers.

    Specifications

    Article number
    FR88EX
    Woofer Type
    Full-range
    Nominal Diameter
    3"
    Power Handling (RMS)
    15 Watts
    Power Handling (max)
    30 Watts
    Impedance
    8 ohms
    Sensitivity
    84.3 dB 2.83V/1m
    Frequency Response
    95 to 20,000Hz
    Voice Coil Diameter
    1"
    DC Resistance (Re)
    6 ohms
    Resonant Frequency (Fs)
    95 Hz
    Mechanical Q (Qms)
    1.96
    Electromagnetic Q (Qes)
    0.62
    Total Q (Qts)
    0.47
    Diaphragm Mass Inc. Airload (Mms)
    2.36g
    Mechanical Compliance of Suspension (Cms)
    1.2 mm/N
    Surface Area of Cone (Sd)
    27.34 cm²
    BL Product (BL)
    3.31 Tm
    Compliance Equivalent Volume (Vas)
    0.04 ft.³
    Maximum Linear Excursion (Xmax)
    3 mm
    Cone / Diaphragm Material
    Aluminum
    Surround Material
    Polyurethane
    Basket / Frame Material
    Steel
    Magnet Material
    Neodymium
    Overall Outside Diameter
    3.48”
    Overall Depth
    1.5"
    Baffle Cutout Diameter
    2.87"
    # Mounting Holes
    4
    Sealed Volume
    0.2 ft.³
    Sealed F3
    161 Hz
    Vented Volume
    0.05 ft.³
    Vented F3
    79 Hz
