        FR135EX 5" Full Range Speaker

        Fountek FR135EX 5" Full Range Speaker

        €99,95

        Out of stock

        Add to cart

        Fountek FR135EX 5" Full Range Speaker

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Fountek
        Show all Full-range woofer
        5" | 8 Ω
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        € 82,60€ 99,95 Out of stock
        • -5% Purchase 4 for only € 94,95 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker
        FR135EX 5" Full Range Speaker

        Product description Fountek FR135EX Full-range Woofer

        Fountek’s FR135EX 5" full range driver features an attractive, high-strength aluminum cone, robust cast-aluminum frame, and an optimized long-excursion neodymium motor, for low distortion and excellent detail.



        Highlights

        • Black anodized aluminum cone with phase plug
        • 40 watts RMS power handling
        • Neo-powered, high-excursion, underhung motor design
        • Smooth, extended frequency response
        • Cast aluminum frame



        Product details

        Fountek FR135EX 5" Neodymium Full Range Speaker Driver



        Fountek has applied much of what it has learned from designing industry-leading ribbon transducers in creating its line of full-range drivers. These high-performing cone drivers feature optimized aluminum diaphragms that shed resonance rapidly, for exceptional detail and smooth frequency response.



        The 5" FR135EX model features a high-strength neodymium motor structure for low distortion, extended excursion, and excellent transient response. It’s perfect as a full-range driver or a midrange in multi-way speaker designs.

        Show more

        Specifications

        Article number
        FR135EX
        EAN
        0848864004204
        Woofer Type
        Full-range
        Nominal Diameter
        5"
        Power Handling (RMS)
        40 Watts
        Power Handling (max)
        80 Watts
        Impedance (Z)
        8 ohms
        Sensitivity (SPL at 1m / 2.83V)
        85.1 dB
        Frequency Response
        50 to 20,000Hz
        Voice Coil Diameter
        1.26"
        Resonant Frequency (Fs)
        61.5 hz
        Mechanical Q (Qms)
        1.71
        Electromagnetic Q (Qes)
        0.69
        Total Q (Qts)
        0.49
        Diaphragm Mass Inc. Airload (Mms)
        7.55g
        Mechanical Compliance of Suspension (Cms)
        0.89 mm/N
        Surface Area of Cone (Sd)
        70.5 cm²
        BL Product (BL)
        5.03 Tm
        Compliance Equivalent Volume (Vas)
        0.22 ft.³
        Maximum Linear Excursion (Xmax)
        5 mm
        Cone / Diaphragm Material
        Aluminum
        Surround Material
        Foam
        Basket / Frame Material
        Cast Aluminum
        Magnet Material
        Neodymium
        Overall Outside Diameter
        5.73”
        Overall Depth
        2.71"
        Baffle Cutout Diameter
        4.53"
        # Mounting Holes
        4
        Sealed Volume
        0.13 ft.³
        Sealed F3
        100 Hz
        Vented Volume
        0.34 ft.³
        Vented F3
        48 Hz

        Show more
