        CE30MB-16B 1-1/4" Mini Speaker

        CE30MB-16B 1-1/4" Mini Speaker

        €3,95

        Add to cart

        Dayton Audio CE30MB-16B 1-1/4" Mini Speaker

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Dayton Audio
        Show all Micro speaker
        1¼" | 16 Ω
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        € 3,26€ 3,95 3 In stock
        • -5% Purchase 4 for only € 3,75 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • Five-year warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker
        CE30MB-16B 1-1/4" Mini Speaker

        Product description

        The Dayton Audio CE30MB-16B is a compact headphone-style mini speaker with a black Mylar diaphragm and 16 ohm impedance.



        Highlights

        • Lightweight headphone-style mylar diaphragm
        • Rugged plastic frame with raised edge for mounting
        • Powerful neodymium magnet
        • Suitable for headphone applications
        • 16 ohm impedance



        Product details

        Dayton Audio CE Series CE30MB-16B 1-1/4" Mini Speaker Black 16 Ohm

        The Commercial Engineering (CE) series of speaker drivers from Dayton Audio provides engineers, designers, and integrators with a line of economical small drivers that fit the diverse range of applications found in consumer electronics and audio-enabled electronic projects.

        The Dayton Audio CE30MB-16A is a compact, high-efficiency "headphone-style" mini speaker with a lightweight Mylar diaphragm and extended frequency range. It’s a rugged choice for adding audio to inexpensive headphones, electronic toys, and portable electronics.



        Note: The Mylar diaphragm is very fragile. To prevent damage, avoid contact with the diaphragm when handling. This driver should be installed behind a grille.

        Show more

        Specifications

        Article number
        CE30MB-16B
        Woofer Series
        CE series
        Woofer Type
        Micro speaker
        Nominal Diameter
        1"
        Power Handling (RMS)
        0.5 Watts
        Power Handling (max)
        1.0 Watts
        Impedance (Z)
        16 ohms
        Sensitivity (SPL at 1m / 2.83V)
        74 dB
        Frequency Response
        400 to 5,000 Hz
        Voice Coil Diameter
        0.5"
        DC Resistance (Re)
        15.7 ohms
        Voice Coil Inductance (Le)
        1.35 mH
        Resonant Frequency (Fs)
        401 Hz
        Mechanical Q (Qms)
        2.55
        Electromagnetic Q (Qes)
        5.28
        Total Q (Qts)
        1.72
        Diaphragm Mass Inc. Airload (Mms)
        0.05g
        Mechanical Compliance of Suspension (Cms)
        3.23 mm/N
        Surface Area of Cone (Sd)
        3.1 cm²
        BL Product (BL)
        0.60 Tm
        Maximum Linear Excursion (Xmax)
        0.1 mm
        Cone / Diaphragm Material
        Poly / Mylar Diaphragm
        Magnet Material
        Neodymium
        Overall Outside Diameter
        1.17"
        Overall Depth
        0.20"
        Baffle Cutout Diameter
        1.04"

        Show more
