Name: Duelund Coherent Audio JDM-PIO-12-CU-0,27 | 0,27 mH | 5% | 12 AWG | JDM Wax PIO Pure Copper Foil Air-Core Inductor
Brand: Duelund Coherent Audio
SKU: JDM-PIO-12-CU-0.27
Price: 82.95 EUR
Availability: InStock

New

JDM-PIO-12-CU-0,27 | 0,27 mH | 5% | 12 AWG | JDM Wax PIO Pure Copper Foil Air-Core Inductor

€ 68,55€ 82,95 2 In stock

We ship to
Same day shipping
At least two years warranty
45-day cooling-off period to return

Customer rating:

Compare

Request quotation

Do you have a question about this product?

Our employee is happy to help you find the right product

Product description Duelund Coherent Audio JDM-PIO-12-CU-0,27 | 0,27 mH | 5% | 12 AWG

The Duelund Coherent Audio JDM-PIO-12-CU-0,27 is a 0.27 mH air-core copper foil inductor for high-quality loudspeaker crossover designs, built with annealed pure copper foil, waxed/oiled paper insulation and deep vacuum impregnation.

Highlights of the JDM-PIO-12-CU-0,27

0.27 mH JDM Wax PIO pure copper foil air-core inductor
12 AWG copper foil construction using 150 micrometre foil with 20 mm height
Waxed/oiled paper insulation with zero plastic construction
Fully deep vacuum impregnated under high pressure, not simply dipped in wax
Designed for loudspeaker crossover networks, filters and audio electronics
High mechanical stability and damping to help reduce microphony

Product details JDM-PIO-12-CU-0,27

Duelund Coherent Audio JDM-PIO-12-CU-0,27 0.27 mH 5% 12 AWG JDM Wax PIO Pure Copper Foil Air-Core Inductor

The JDM-PIO-12-CU-0,27 is an entry-level Duelund air-core copper foil inductor made for demanding loudspeaker crossover work. As one of the key crossover components in a speaker design, it uses annealed pure copper foil instead of conventional wire to support a clean, natural and dynamic response with low loss.

Duelund builds these coils from 150 micrometre thick copper foil with a 20 mm height, corresponding to 12 AWG. The foil is wound onto a compressed paper former and insulated with waxed/oiled paper, while the integral foil itself is used as the terminal material for a direct and robust construction.

The JDM Wax PIO construction is fully deep vacuum impregnated under high pressure with Duelund’s proprietary WPIO dielectricum. This process takes several days and gives the inductor strong damping properties, high mechanical stability and reduced sensitivity to vibration and microphony.

Designed for audio crossover networks, filters and electronics, this inductor is especially suited to high-quality speakers where component behaviour directly affects the final sound. Its zero-plastic build, pure copper foil conductor and wax/paper/oil dielectric make it a refined choice for serious DIY loudspeaker projects.
