    TPA3116D2.1-BT Class D Amplifier Board

    € 57,81€ 69,95 >10 Auf Lager: Lieferzeit 1-3 Werktage
    Bulk discount Genießen Sie diese tollen Rabattangebote
    • -5% Kauf 4 für nur €66,45 pro stück
    • Versicherter Versand mit Sendungsverfolgung
    • Kostenloser Versand ab 149€ (DE, A)
    • Versand am selben Tag
    • Hausinterner technischer Support
    Haben Sie eine Frage zu diesem Produkt?

    Haben Sie eine Frage zu diesem Produkt?

    Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

    Produktbeschreibung

    Enjoy creating new audio projects with this all-in-one, easy to use 5.0 Bluetooth 2.1 channel small amplifier board with bass, treble, and variable low pass filter controls. Its delivers 50W into stereo channels and an additional 100W into a mono subwoofer channel for making a big sounding boom box, portable speaker, or even a mobile power amp.



    Highlights

    • 12 to 24 VDC for versatility
    • DC power jack, 3.5 mm Aux-in jack, and Phoenix speaker connectors for quick hookup
    • Built-in master volume, treble, satellite volume, subwoofer volume, and low-pass filter potentiometers for sound customization
    • Pre-assembled and pre-tested for easy project integration
    • Class D efficiency and wireless 5.0 Bluetooth in one compact size board
    • Easily switch between Bluetooth and line-in source by pushing and holding in the master volume control for three seconds



    Product details

    TPA3116D2.1-BT 2 x 50W + 100W Class D 2.1 Bluetooth 5.0 Amplifier Board with Filter and Volume Controls



    Make your own 2.1 multimedia wireless Bluetooth amplifier or portable speaker with this 2 x 50W + 100W amplifier board. The board accepts 12 VDC to 24 VDC which makes it perfect for making home or mobile audio projects. Make your audio project truly portable by adding three to five 18650 Li-Ion batteries.



    These boards are pre-tested and pre-assembled, which makes your project easy to complete. The on-board jacks, potentiometer, and screw terminals let you get this board powered up and playing music in minutes. Just connect your power source using a 2.1 x 5.5 mm DC power plug, a 3.5 mm stereo audio source, and run speaker wire from the six screw terminals to you speakers and you are done. If you don't want to use the 3.5 mm jack, an optional 3-pin connector for internal line-in audio is available (wiring harnesses not included). Push and hold in the master volume control for three seconds to switch from Bluetooth to line-in source. Push in master volume control to switch back to Bluetooth.

    Eigenschaften

    Artikelnummer:
    TPA3116D2.1-BT
    Nennleistung
    2 x 50 watt + 1 x 100 watt at 4 ohms
    Mindestlast
    4 ohms
    Effizienz
    -
    Signal-Rausch-Verhältnis (SNR)
    100 dB
    Verzerrung
    -
    Frequenzgang
    20 - 20,000 Hz
    Verstärkungsfaktor
    -
    Eingangsempfindlichkeit
    -
    Eingangsimpedanz
    -
    Amplifier Classification
    Class D
    Verstärkertopologie
    Texas Instruments TPA3116D2
    Ausgangskanäle
    3
    Eingangsanschlusstyp
    3.5 mm stereo jack or 3-pin line-in socket
    Ausgangsanschluss
    Screw terminal
    DSP-Funktion
    -
    Bluetooth
    EQ-Korrektur
    Leistungsbedarf
    12 - 24 VDC
    Stromanschlussstecker
    DC jack 2.1 x 5.5 mm or srew terminals
    Derzeitige Begrenzung
    3 A
    Unter- / Überspannungsschutz
    -
    Abmessungen (L x B x H)
    100 x 100 x 23 mm without potmeter (shaft length potmeter: 15.3 mm)
    Abstand zwischen Befestigungslöchern
    -
    Durchmesser Befestigungslochs
    -

    Mehr anzeigen

    Bewertungen

    4 from 5Based on 7 reviews
    Produkt bewerten
    4 von 5
    Overall a good amp for the price but only for the price. The great thing is that its easy to set up and it has many pots to change the sound. Im not sure about the 100w on the sub-out tho. It more seems like 50w and the bass also starts to distort and is unuseable above 50-60% volume. Most 8" and 6.5" subwoofers will already be underpowered by those "100W" of bass. The 50w on the L and R channel seem legit, altough it still doesent get that loud on full volume. The bluetooth connection however is fantastic, speaker is in the first floor of the house, I am standing on the third floor with many walls inbetween and the connection is still perfectly fine.
    Durch GIZMO320 on 8 Januar 2022
    3 von 5
    Tut was es soll. Keine Doku; Schiebeschalter zwischen den Potis ohne Beschriftung. Das Pairing/Umschalten zwischen Line-In und Bluetooth ist hakelig.
    Durch Uwe H. on 29 September 2020
