- Artikelnummer:
- W 130 X
- Woofer Series
- W Series
- Woofer Type
- Midwoofer
- Nominal Diameter
- 5"
- Power Handling (RMS)
- 60 Watts
- Power Handling (max)
- 90 Watts
- Impedance
- 4+4 ohms
- Sensitivity
- 78 dB (1 W/1 m)
- Frequency Response
- 40 - 6,000 Hz
- Voice Coil Diameter
- 40 mm
- DC Resistance (Re)
- 2.0 - 7.9 ohms
- Voice Coil Inductance (Le)
- 0.69 - 2.75 mH
- Resonant Frequency (Fs)
- 40 Hz
- Mechanical Q (Qms)
- 4.27 - 4.59
- Electromagnetic Q (Qes)
- 0.41 - 0.86
- Total Q (Qts)
- 0.37 - 0.71
- Diaphragm Mass Inc. Airload (Mms)
- 37g
- Surface Area of Cone (Sd)
- 94.2 cm2
- BL Product (BL)
- 6.5 - 13.2 Tm
- Compliance Equivalent Volume (Vas)
- 5.1 - 5.64 Liters
- Maximum Linear Excursion (Xmax)
- 3 mm
- Cone / Diaphragm Material
- Polypropylene
- Dual Voice Coil
- check
- Overall Outside Diameter
- 148.2 mm
- Overall Depth
- 72 mm
- Baffle Cutout Diameter
- 123 mm
- Bolt Circle Diameter
- 141 mm
- # Mounting Holes
- 4
- Mounting Hole Diameter
- 4.3 mm
