Visaton W 130 S - 8 5" Woofer 8 Ohm

Lieferzeit: 1-3 Werktage

  • Artikelnummer: W 130 S - 8
  • Vorrat: 4 Auf Lager

The 9023 W130S 5" woofer from Visaton delivers amazing bass, Xmax, and midrange performance not normally found in 5" drivers at its price point.

€ 29,95 Inkl. MwSt.

  • Kaufen Sie 4 für je €28,45 und sparen Sie 5% Sale 5%

Auf den Wunschzettel

  • Gratis DHL-Versand ab 149€ (DE, A) Tooltip

    Bestellungen an Werktagen vor 16Uhr werden noch am selben Tag versandt. Weitere Informationen

  • Versand am selben Tag
  • 45 Tage Bedenkzeit
  • Zahlung mit Paypal/Kreditkarte

Produktbeschreibung

Visaton W 130 S - 8 5" Woofer 8 Ohm

Highlights

  • Relatively flat frequency response from 80 to 4,000 Hz
  • Able to play below 40 Hz in a proper vented cabinet
  • Great power handling and Xmax



Product Details

Visaton W 130 S - 8 5" Woofer 8 Ohm



Visaton's 9023 W130S 5" woofer features a coated paper cone and durable rubber surround. A very balanced frequency response allows the W130S to be used as a woofer in small two-way speakers or a midbass/midrange in three-way speakers, with a crossover point as high as 4,000 Hz. This allows you to build a surround sound system with large speakers for front and left, while maintaining the same voicing in smaller surround satellite speakers.



For best bass performance, install the W130S into one of the following cabinets: A 0.25 cubic foot sealed cabinet (F3 is 86 Hz with a Qtc of 0.75) • A 0.71 cubic foot cabinet tuned to 44 Hz with a 1-1/4" diameter port that is 1-9/16" long • A 1.06 cubic foot cabinet tuned to 39 Hz with a 2-3/8" diameter port that is 4-3/4"" long.

Eigenschaften

Spezifikationen für: W 130 S - 8 5" Woofer 8 Ohm

  • Woofer Series Spezielle Woofer- Produktionsreihe des Herstellers. HiFi Series
  • Woofer Type Art des Drivers, wie zum Beispiel, Subwoofer, Midwoofer, Full-range, Coaxial-Woofer Bass-mid woofer
  • Nominal Diameter Ungefährer Durchmesser des Drivers, gemessen in Inch. 5"
  • Power Handling (RMS) Durchschnittliche elektrische Bestlastbarkeit eines Lautsprechers in Watt, ohne den Driver zu beschädigen. RMS = Root Mean Square steht für Root Mean Square. 50 watts
  • Power Handling (max) Die maximale kurzzeitige elektrische Belastbarkeit eines Lautsprechers in Watt, bevor es zu Schäden kommt. 80 watts
  • View all specifications
  • Continuous Program Power
  • Impedance 8 ohms
  • Sensitivity 87 dB 1W/1m
  • Frequency Response 52 - 12,000 Hz
  • Voice Coil Diameter 1"
  • Magnet Weight
  • DC Resistance (Re) 6 ohms
  • Voice Coil Inductance (Le) 0.6 mH
  • Resonant Frequency (Fs) 52 Hz
  • Mechanical Q (Qms) 2.26
  • Electromagnetic Q (Qes) 0.59
  • Total Q (Qts) 0.47
  • Diaphragm Mass Inc. Airload (Mms)
  • Moving Mass Of Diaphragm (Mmd)
  • Mechanical Compliance of Suspension (Cms)
  • Surface Area of Cone (Sd)
  • Volume of Displacement (Vd)
  • BL Product (BL)
  • Compliance Equivalent Volume (Vas) 0.42 ft.³
  • Maximum Linear Excursion (Xmax) 2.25 mm
  • Driver's Mechanical Losses (Rms)
  • Cone / Diaphragm Material Treated Paper
  • Surround Material Rubber
  • Voice Coil Wire Material
  • Voice Coil Former
  • Dual Voice Coil
  • Basket / Frame Material
  • Magnet Material
  • Shielded
  • Overall Outside Diameter 146 mm
  • Overall Depth 53.1 mm
  • Baffle Cutout Diameter 106.9 mm
  • Bolt Circle Diameter
  • # Mounting Holes 5
  • Mounting Hole Diameter
  • Sealed Volume 5.95 liters
  • Sealed F3 88 Hz
  • Vented Volume 15.86 liters
  • Vented F3 43 Hz
