Visaton KE 25 SC 1" High-End Tweeter 8 Ohm

€ 134,95 >10 Auf Lager: Lieferzeit 1-3 Werktage
25 mm (1") High-end magnetically shielded tweeter with ceramic diaphragm for crystal clear perfectly reproduced sound without distortion, even at high volume.... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €128,20 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

25 mm (1") High-end magnetically shielded tweeter with ceramic diaphragm for crystal clear perfectly reproduced sound without distortion, even at high volume.



Highlights

  • Ceramic dome
  • Great omnidirectional sound distribution at high frequency’s
  • Linearized impedance due to integrated LRC element



Product details

Visaton KE 25 SC 1" High-End Tweeter



This tweeter has a perforated pole piece coupled with the flow-optimized rounded shape, the damping in the cavity and the ventilated voice coil carrier guarantee a very low resonance frequency. The impedance is linearized by means of an integrated LRC element. This means that the dome can be easily integrated in a network of crossovers. The protective grille is fitted on the inside with an acoustic low-pass filter in the shape of a transparent ring, which does not begin to operate until 25 kHz are achieved, when it damps any material-borne resonance. The grille has the added advantage of improving omnidirectional sound distribution at higher frequencies..

Eigenschaften

Artikelnummer:
KE 25 SC
Tweeter Type
Dome
Tweeter Series
High-End
Cone / Dome Diameter
1"
Power Handling (RMS)
80 Watts
Power Handling (max)
140 Watts
Impedance
8 ohms
Sensitivity
89 dB (1 W/1 m)
Frequency Response
800 - 25,000 Hz
Resonant Frequency (Fs)
Compensated
DC Resistance (Re)
5.9 ohms
Overall Outside Diameter
104.5 mm
Cutout Diameter
82 mm
Depth
60 mm
Diaphragm Material
Ceramic
Recommended cut frequency
>1,500 Hz

Bewertungen

5 from 5Based on 1 reviews
Produkt bewerten
5 van 5
Incredible precision, it can take an unexpected amount of power and still sounds softer than any other metal tweeter that we ever try. Flat from 2-22khz with only 4 corrections on PEQ , overall performs better than some units which are 4 times the price!
Durch Simon on 26 Januar 2020
