Tang Band W4-1320SIF 4" Bamboo Full Range Speaker

€ 53,68€ 64,95 >10 Auf Lager: Lieferzeit 1-3 Werktage
Bamboo, highly regarded for its strength and durability, is an important part of the Tang Band W4-1320SIF 4" speaker's excellent audio performance.... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €61,70 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

Bamboo, highly regarded for its strength and durability, is an important part of the Tang Band W4-1320SIF 4" speaker's excellent audio performance.



Highlights

  • Features a bamboo fiber paper cone with half-roll rubber surround
  • A strong cast aluminum chassis maintains proper component alignment
  • Also available in a truncated frame version



Product details

Tang Band W4-1320SIF 4" Bamboo Full Range Speaker



Tang Band's W4-1320SIF 4" speaker features a bamboo fiber paper cone with half-roll rubber surround. This optimally damped cone material is rigid, lightweight, and durable. The driver's 18 oz. ceramic ferrite magnet and underhung 1" voice coil do their part to ensure very low 2nd and 3rd order distortion. A machined aluminum phase plug improves high frequency performance, and a strong cast aluminum chassis maintains proper component alignment. Also available in a truncated frame version, the W4-1320SJF.

Eigenschaften

Artikelnummer:
W4-1320SIF
Woofer Type
Full-range
Nominal Diameter
4"
Power Handling (RMS)
25 Watts
Power Handling (max)
50 Watts
Impedance
8 ohms
Sensitivity
88 dB 1W/1m
Frequency Response
75 to 20,000 Hz
Voice Coil Diameter
1"
Magnet Weight
18.6 oz.
DC Resistance (Re)
6.3 ohms
Voice Coil Inductance (Le)
0.02 mH
Resonant Frequency (Fs)
75 Hz
Mechanical Q (Qms)
2.52
Electromagnetic Q (Qes)
0.42
Total Q (Qts)
0.36
Diaphragm Mass Inc. Airload (Mms)
3.99g
Mechanical Compliance of Suspension (Cms)
1.13 mm/N
Surface Area of Cone (Sd)
57 cm²
BL Product (BL)
5.31 Tm
Compliance Equivalent Volume (Vas)
0.18 ft.³
Maximum Linear Excursion (Xmax)
3 mm
Cone / Diaphragm Material
Bamboo Fiber / Paper
Surround Material
Rubber
Basket / Frame Material
Cast Aluminum
Magnet Material
Ferrite
Overall Outside Diameter
4.94"
Overall Depth
3.24"
Baffle Cutout Diameter
3.74"
# Mounting Holes
4
Sealed Volume
0.04 ft.³
Sealed F3
166 Hz
Vented Volume
0.1 ft.³
Vented F3
96 Hz

Bewertungen

5 from 5Based on 1 reviews
Produkt bewerten
5 van 5
goede kwaliteit luidspreker, met uitstekend geluid.
good quality loudspeaker, with excellent sound.
Durch J T. on 6 Januar 2021
