- Artikelnummer:
- W3-881SJF
- Woofer Type
- Full-range
- Nominal Diameter
- 3"
- Power Handling (RMS)
- 15 Watts
- Power Handling (max)
- 30 Watts
- Impedance
- 8 ohms
- Sensitivity
- 88 dB 1W/1m
- Frequency Response
- 100 to 20,000 Hz
- Voice Coil Diameter
- 0.8"
- Magnet Weight
- 7.7 oz.
- DC Resistance (Re)
- 6.6 ohms
- Voice Coil Inductance (Le)
- 0.8 mH
- Resonant Frequency (Fs)
- 100 Hz
- Mechanical Q (Qms)
- 6.44
- Electromagnetic Q (Qes)
- 0.41
- Total Q (Qts)
- 0.39
- Diaphragm Mass Inc. Airload (Mms)
- 2g
- Mechanical Compliance of Suspension (Cms)
- 1.32 mm/N
- Surface Area of Cone (Sd)
- 32 cm²
- BL Product (BL)
- 4.47 Tm
- Compliance Equivalent Volume (Vas)
- 0.07 ft.³
- Maximum Linear Excursion (Xmax)
- 0.5 mm
- Cone / Diaphragm Material
- Poly
- Surround Material
- Santoprene®
- Voice Coil Wire Material
- CCA
- Voice Coil Former
- Kapton® / Polyimide
- Basket / Frame Material
- Cast Aluminum
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 3.66"
- Overall Depth
- 2.32"
- Baffle Cutout Diameter
- 2.95"
- # Mounting Holes
- 4
- Sealed Volume
- 0.02 ft.³
- Sealed F3
- 207 Hz
- Vented Volume
- 0.05 ft.³
- Vented F3
- 115 Hz
