Tang Band W3-1364SA 3" Bamboo Cone Driver

€ 30,12€ 36,45 9 Auf Lager: Lieferzeit 1-3 Werktage
A blend of paper and Bamboo fibers provides a perfect combination of light weight and self-damping. A neodymium motor with a copper ring reduces distortion even further. The result of these features is a smooth frequency response with a very natural, open... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €34,63 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

A blend of paper and Bamboo fibers provides a perfect combination of light weight and self-damping. A neodymium motor with a copper ring reduces distortion even further. The result of these features is a smooth frequency response with a very natural, open sound.



Highlights

  • Paper cone reinforced with bamboo fibers reduces cone resonances
  • Copper shorting ring lowers inductance and distortion
  • Powerful neodymium motor cuts weight without sacrificing performance
  • Suprisingly smooth response from 100 to 20,000 Hz



Product details

Tang Band W3-1364SA 3" Bamboo Cone Driver



Another Tang Band first, Bamboo fiber cones! A blend of paper and Bamboo fibers provides a perfect combination of light weight and self-damping. A neodymium motor with a copper ring reduces distortion even further. The result of these features is a smooth frequency response with a very natural, open sound.

Eigenschaften

Artikelnummer:
W3-1364SA
Woofer Type
Full-range
Nominal Diameter
3"
Power Handling (RMS)
12 Watts
Power Handling (max)
25 Watts
Impedance
8 ohms
Sensitivity
86 dB 1W/1m
Frequency Response
105 to 20,000 Hz
Voice Coil Diameter
0.75"
DC Resistance (Re)
6.6 ohms
Resonant Frequency (Fs)
105 Hz
Mechanical Q (Qms)
2.48
Electromagnetic Q (Qes)
0.77
Total Q (Qts)
0.59
Compliance Equivalent Volume (Vas)
0.07 ft.³
Maximum Linear Excursion (Xmax)
0.5 mm
Cone / Diaphragm Material
Bamboo Fiber / Paper
Magnet Material
Neodymium
Overall Outside Diameter
3.625"
Overall Depth
2"
Baffle Cutout Diameter
3"
# Mounting Holes
4
Sealed Volume
0.08 ft.³
Sealed F3
143 Hz
Vented Volume
0.15 ft.³
Vented F3
71 Hz
