SEAS Prestige L18RNX/P - H1224 7" Aluminum Cone Woofer

€ 74,34€ 89,95 >10 Auf Lager: Lieferzeit 1-3 Werktage
L18RNX/P is a 6,5” High Fidelity woofer with an injection molded metal chassis, intended for bass reflex and transmission line designs.... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €85,45 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

Highlights

  • Long term power handling (RMS) is 100 Watts
  • Injection molded metal chassis, intended for bass reflex and transmission line designs
  • Seas SpiderRing® technology



Product details

L18RNX/P is a 6,5” High Fidelity woofer with an injection molded metal chassis, intended for bass reflex and transmission line designs. Stiff, yet light aluminum cone and low loss rubber surround show no sign of the familiar 500-1500 Hz cone edge resonance and distortion associated with soft cones.



The large magnet system gives a good transient response, and the bumped back plate together with the very long, and light weight copper clad aluminum voice coil allow for extreme coil excursion with low distortion.



Extremely stiff and stable injection molded metal basket, keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound reflection, air flow noise and cavity resonance to a minimum.

Eigenschaften

Artikelnummer:
L18RNX/P
Woofer Series
Prestige Series
Woofer Type
Midwoofer
Nominal Diameter
7"
Power Handling (RMS)
100 Watts
Power Handling (max)
250 Watts
Impedance
8 ohms
Sensitivity
88 dB 2.83V/1m
Frequency Response
45 to 3,000 Hz
Voice Coil Diameter
1.54"
Magnet Weight
22.6 oz.
DC Resistance (Re)
5.8 ohms
Voice Coil Inductance (Le)
1.06 mH
Resonant Frequency (Fs)
36 Hz
Mechanical Q (Qms)
2.09
Electromagnetic Q (Qes)
0.36
Total Q (Qts)
0.31
Diaphragm Mass Inc. Airload (Mms)
13.6g
Mechanical Compliance of Suspension (Cms)
1.4 mm/N
Compliance Equivalent Volume (Vas)
0.88 ft.³
Maximum Linear Excursion (Xmax)
6 mm
Overall Outside Diameter
6.93"
Overall Depth
3.28"
Baffle Cutout Diameter
5.72"
Bolt Circle Diameter
6.54"
# Mounting Holes
6
Mounting Hole Diameter
0.2"
