SEAS Prestige L12RE/XFC - H1602-04/06 5" Alum/Fabric Coaxial Woofer

Name: SEAS Prestige L12RE/XFC - H1602-04/06 5" Alum/Fabric Coaxial Woofer
Brand: SEAS
Price: 154.95 EUR
Availability: InStock
Rating: 5 (1 reviews)

Marke: SEAS

Alle anzeigen Audio-Komponenten

Vergleichen

5" | 4 Ω

Prestige L12RE/XFC - H1602-04/06 5" Alum/Fabric Coaxial Woofer

€ 154,95 2 Auf Lager: Lieferzeit 1-3 Werktage

The L12RE/XFC is a coaxial loudspeaker providing high quality sound in a very compact format. The coaxially arranged precoated fabric dome high frequency unit has a low resonance frequency and integrates with the cone driver to a point source.... Mehr anzeigen

Versicherter Versand mit Sendungsverfolgung
Kostenloser Versand ab 149€ (DE, A)
Versand am selben Tag*
Hausinterner technischer Support

Produktbeschreibung

Highlights

Long term power handling (RMS) is 80 Watts (Woofer) and 90 Watts (Tweeter)
Coaxial loudspeaker providing high quality sound in a very compact format
The cone of the woofer acts as a moderate horn loading for the tweeter, and the chassis of the dome unit represents the throat of this horn

Product details

Seas Prestige L12RE/XFC - H1602-04/06 5" Alum/Fabric Coaxial Woofer

Voice coil windings immersed in magnetic fluid increase short term power handling capacity and reduce the compression at high power levels. The cone of the woofer acts as a moderate horn loading for the tweeter, and the chassis of the dome unit represents the throat of this horn.

The stiff, yet light aluminum cone acts as a piston throughout the recommended frequency range.

Eigenschaften

Artikelnummer:: L12RE/XFC
Woofer Series: Prestige Series
Woofer Type: Coaxial
Nominal Diameter: 5"
Power Handling (RMS): 80 Watts
Power Handling (max): 250 Watts
Impedance: 4 ohms
Sensitivity: 86 dB 2.83V/1m
Frequency Response: 60 - 25,000 Hz
Voice Coil Diameter: 1.53"
Magnet Weight: 14.8 oz.
DC Resistance (Re): 3.1 ohms
Voice Coil Inductance (Le): 0.48 mH
Resonant Frequency (Fs): 55 Hz
Mechanical Q (Qms): 2.99
Electromagnetic Q (Qes): 0.33
Total Q (Qts): 0.30
Diaphragm Mass Inc. Airload (Mms): 0.19g
Mechanical Compliance of Suspension (Cms): 0.9 mm/N
Compliance Equivalent Volume (Vas): 0.10 ft.³
Maximum Linear Excursion (Xmax): 3 mm
Overall Outside Diameter: 4.72"
Overall Depth: 2.91"
Baffle Cutout Diameter: 3.77"
Bolt Circle Diameter: 4.36"
# Mounting Holes: 6

Bewertungen

5 from 5Based on 1 reviews

Produkt bewerten

5 van 5

Sagenhafte Räumlichkeit, Bühne und Ablösung der Musik von den Lautsprechern. Der sogenannte ''Sweetspot'' ist hier sehr weit gefächert, selbst wenn man seitlich er Lautsprecher sitzt, hat man noch ein ordentliches Stereobild mit guter Bühne. Absolut empfehlenswert für Drei-Wege Konstruktionen mit entsprechender Unterstützung durch einen Tieftöner in der Box.

Durch Harald L. on 18 November 2020
