Scan-Speak 5F/8422T01 2'' Full Range Driver

€ 49,55€ 59,95 2 Auf Lager: Lieferzeit 1-3 Werktage
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €56,95 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements - plus a wealth of technical features and finesses - gives our customers the possibility of acquiring a tailor-made Scan-Speak solution with very good performance at a reasonable low price point!



Highlights

  • Powerful Neo Ring Motor, Symmetric Drive
  • 1" Voice Coil, Ti Former, European Soft Parts
  • Paper Cone, Foam Surround, Long Excursion
  • Large Pole Piece Vent, Low Distortion
  • Wide Frequency Range
  • Extended Copper Cap on Pole Piece



Product details

Scan-Speak 5F/8422T01 2'' Full Range Driver



The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements - plus a wealth of technical features and finesses - gives our customers the possibility of acquiring a tailor-made Scan-Speak solution with very good performance at a reasonable low price point! The Scan-Speak 5F/8422T01 Full Range Driver boasts all the good stuff that you are used to seeing when looking at a Scan-Speak driver. A powerful motor, well designed soft parts and low distortion.

Eigenschaften

Artikelnummer:
5F/8422T01
Tieftöner-Serie
Discovery Series
Tieftönertyp
Full-range
Nenndurchmesser
2"
Belastbarkeit (QMW)
10 Watts
Belastbarkeit (max)
20 Watts
Impedanz (Z)
8 ohms
Empfindlichkeit
80 dB 2.83V/1m
Frequenzgang
100 to 20,000 Hz
Schwingspulendurchmesser
1"
Gleichstromwiderstand (Re)
6.0 ohms
Schwingspuleninduktion (Le)
0.07 mH
Resonanzfrequenz (Fs)
93 Hz
Mechanische Güte (Qms)
5.17
Elektrische Güte (Qes)
0.69
Gesamtgüte (Qts)
0.61
Bewegliche Masse (Mms)
1.86g
Nachgiebigkeit der Aufhängung (Cms)
1.58 mm/N
Membranfläche (Sd)
15.2 cm²
Kraftfaktor (BL)
3.07 Tm
Äquivalentvolumen (Vas)
0.02 ft.³
Maximale Auslenkung (Xmax)
2 mm
Driver's Mechanical Losses (Rms)
0.21 kg/s
Cone / Diaphragm Material
Paper
Sicke-Material
Foam
Schwingspulenformmaterial
Titanium
Dual Voice Coil
No
Korb- / Rahmenmaterial
Aluminum
Magnetmaterial
Neodymium
Magnetisch abgeschirmt
No
Außendurchmesser
2.64''
Gesamttiefe
1.30''
Ausschnittdurchmesser
2.11''
Bolt Circle Diameter
2.38''
# Befestigungsbohrungen
4
Durchmesser Befestigungslochs
0.13''

Bewertungen

5 from 5Based on 2 reviews
Produkt bewerten
4 van 5
Sounds incredibly full for such a tiny speaker!
The foam surround could be an issue but still its very high quality foam, it will last quite a while.
One thing I have to complaint is, that the basket is made out of plastic not that it would bad but if you try to solder the wires on the terminal, the plastic will melt veeery quickly, the plastic is pretty soft too so be careful with that.
Also what has happened is that the magnet has come loose! I really am very careful with my speakers but this is the second time this ever happened to me.
But no problem, I glued it carefully back, still is fine.
Overall opinion:
Very full bodied sound, balanced, great excursion, simply Scan-Speak sound.
But its very fragile, it can break easily, however builtquality is great.
Durch GIZMO320 on 23 Januar 2021
5 van 5
Koper heeft geen omschrijving achtergelaten.
Durch Derk Jan R. on 13 März 2020
