      ROSSO-10CX300 10'' Coaxial Woofer

      SB Audience ROSSO-10CX300 10'' Coaxial Woofer

      €289,95

      2 Auf Lager

      Zum Warenkorb hinzufügen

      SB Audience ROSSO-10CX300 10'' Coaxial Woofer

      0 reviews
      0 von 5
      0 reviews
      5 Sterne
      0%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      0%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      Marke: SB Audience
      Zeige alle Koaxiallautsprecher
      10" | 8 + 8 Ω
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      239,63 €289,95 € 2 Auf Lager
      • -5% Bestelle 4 für nur 275,45 € je Stück
      +-
      Zum Warenkorb hinzufügen

      Buy now, pay later

      • Kostenloser Versand (DE & A)
      • Vor 16:00 Uhr bestellt, heute versandt
      • Mindestens zwei Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      Haben Sie eine Frage zu diesem Produkt?

      Haben Sie eine Frage zu diesem Produkt?

      Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer
      ROSSO-10CX300 10'' Coaxial Woofer

      Produktbeschreibung SB Audience ROSSO-10CX300 Coaxial Woofer

      The ROSSO-10CX300 is a premium 10” coaxial loudspeaker driver built for high-performance audio applications. Featuring a cast aluminum frame, dual ferrite/neo magnet structure, and integrated HF horn, it delivers powerful full-range sound from a compact footprint — ideal for professional PA systems and demanding custom builds.



      Highlights of the ROSSO-10CX300

      • 600W LF + 100W HF power handling for high-output performance
      • Integrated precision HF horn with shared ferrite/neo magnet structure
      • Weather-resistant cone with sisal and manila fiber reinforcement
      • High sensitivity: 95dB LF / 105dB HF for efficient system integration



      Product details ROSSO-10CX300

      ROSSO-10CX300 10” Coaxial Loudspeaker Driver



      The ROSSO-10CX300 is a high-performance 10-inch coaxial loudspeaker designed for applications requiring wide frequency coverage and compact integration. The LF unit features a 300W AES-rated power handling with 95dB sensitivity, operating smoothly from 58Hz to 7300Hz. The 60.6mm ASVCAW voice coil is wound on a fiberglass former for minimal damping and thermal stability. A ferrite magnet with a neodymium slug enhances the flux density (0.94T) for higher SPL and improved transient response.

      The HF section uses a 44.3mm PSVCAR voice coil wound on a Kapton former, powered by a high-efficiency neodymium motor structure delivering 105dB sensitivity across 1.5kHz to 20kHz. It incorporates a precision-machined horn integrated into the cast aluminum frame for controlled directivity and improved off-axis performance.

      Durability is enhanced with a weatherproof coated paper cone reinforced with natural fibers, and the triple-roll cloth surround maintains linear excursion up to 8.2mm Xmax. The driver includes advanced features like a single-height spider for LF linearity and a demodulation-free HF circuit for extended clarity.

      This robust yet compact coaxial unit is ideal for premium stage monitors, compact PA systems, and advanced custom loudspeaker designs demanding clarity, output, and coherence from a single point-source transducer.

      Mehr anzeigen

      Eigenschaften

      Artikelnummer:
      ROSSO-10CX300
      EAN
      9504486348515
      Tieftöner-Serie
      SB Audience Rosso series
      Nenndurchmesser
      10"
      Belastbarkeit (QMW)
      350 Watts
      Belastbarkeit (max)
      700 watts LF, 100 Watts HF
      Impedanz (Z)
      8 + 8 Ω
      Empfindlichkeit (SPL bei 1m / 2,83V)
      96 dB LF, 102 dB HF
      Frequenzgang
      49-6.300 Hz LF, 1.500-20.000 Hz HF
      Schwingspulendurchmesser
      60.6 mm LF, 44.3 mm HF
      Gleichstromwiderstand (Re)
      6.2 Ω LF, 6.8 Ω HF
      Schwingspuleninduktion (Le)
      0.58 mH
      Resonanzfrequenz (Fs)
      49 Hz
      Mechanische Güte (Qms)
      6.99
      Elektrische Güte (Qes)
      0.52
      Gesamtgüte (Qts)
      0.49
      Bewegliche Masse (Mms)
      47.5 g
      Membranfläche (Sd)
      530.9 cm²
      Kraftfaktor (BL)
      12.1 Tm
      Äquivalentvolumen (Vas)
      90.4 Liters
      Maximale Auslenkung (Xmax)
      8.2 mm
      Driver's Mechanical Losses (Rms)
      2.07 Kg/s
      Korb- / Rahmenmaterial
      Aluminum
      Magnetmaterial
      Ferrite, Neo
      Außendurchmesser
      322.5 mm
      Gesamttiefe
      173.5 mm
      Ausschnittdurchmesser
      287 mm
      Bolt Circle Diameter
      306.5 mm
      # Befestigungsbohrungen
      8
      Durchmesser Befestigungslochs
      6.9 mm
