      Satori WO24TX-8 Textreme 9,5" woofer

      Satori WO24TX-8 Textreme 9,5" woofer

      €389,95

      SB Acoustics Satori WO24TX-8 Textreme 9,5" woofer

      1 reviews
      5 von 5
      1 reviews
      5 Sterne
      100%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      0%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      322,27 €389,95 € 8 Auf Lager
      • -5% Bestelle 4 für nur € 370,45 je Stück

      Buy now, pay later

      • Kostenloser Versand (DE & A)
      • Vor 16:00 Uhr bestellt, heute versandt
      • Mindestens zwei Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      Haben Sie eine Frage zu diesem Produkt?

      Haben Sie eine Frage zu diesem Produkt?

      Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

      Produktbeschreibung

      The new SB Acoustics 9.5" Satori WO24TX-4 and WO24TX-8 Textreme woofer models, with an increased rated power at 90W, are an important reinforcement for the Satori range, which now offers extensive options for speaker designers.



      Highlights

      • Advanced TeXtreme® cone for improved piston operation
      • Large optimized motor system with under-cut pole piece and dual shorting rings
      • Vented aerodynamic cast aluminum chassis for optimum strength and low compression.
      • Soft low damping rubber surround for optimum transient response
      • Linear symmetric suspension design for improved dynamic performance
      • Non-conducting fibre glass voice coil former for minimum damping
      • Long life silver lead wires attached 180° apart for improved stability
      • Vented pole piece for reduced compression
      • Low piston to chassis diameter ratio
      • Gasket and bolt hole protrusions for reduced coupling to speaker cabinet.



      Product details

      SB Acoustics Satori WO24TX-8 Textreme woofer


      The company was one of the very first speaker driver manufacturers to announce the adoption of TeXtreme materials for cones and diaphragms and, although it wasn't first to market with TPCD material diaphragms it was probably the brand that most contributed to its market recognition and acceptance. The fact that SB Acoustics launched TeXtreme-based drivers in its Satori high-end audio range, designed by Danesian Audio, was a clear sign of the performance that Frank Nielson and Ulrik Schmidt managed to achieve.

      Mehr anzeigen

      Eigenschaften

      Artikelnummer:
      WO24TX-8
      Tieftöner-Serie
      Satori
      Tieftönertyp
      Textreme woofer
      Nenndurchmesser
      9.5"
      Belastbarkeit (QMW)
      90 W
      Impedanz (Z)
      8 Ω
      Empfindlichkeit (SPL bei 1m / 2,83V)
      88 dB
      Schwingspulendurchmesser
      49.5 mm
      Gleichstromwiderstand (Re)
      5.8 Ω
      Schwingspuleninduktion (Le)
      0.56 mH
      Resonanzfrequenz (Fs)
      24.5 Hz
      Mechanische Güte (Qms)
      5.67
      Elektrische Güte (Qes)
      0.36
      Gesamtgüte (Qts)
      0.34
      Bewegliche Masse (Mms)
      44.2 g
      Nachgiebigkeit der Aufhängung (Cms)
      0.95 mm/N
      Membranfläche (Sd)
      255 cm2
      Kraftfaktor (BL)
      10.45 Tm
      Äquivalentvolumen (Vas)
      88 liters
      Maximale Auslenkung (Xmax)
      8.55 mm
      Driver's Mechanical Losses (Rms)
      1.2 kg/s
      Außendurchmesser
      242 mm
      Gesamttiefe
      131.4 mm
