SB Acoustics SB34NRX75-16 12" Woofer 16 ohm

€ 148,72€ 179,95 2 Auf Lager: Lieferzeit 1-3 Werktage
This new 16 ohm 12″ woofer from SB Acoustic features a low distortion motor system, paper cone with rubber surround, cast Aluminum frame and 75mm voice coil. The woofer would make a fine low frequency driver for a premium 3-way system, or put two in paral... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €170,95 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

Highlights:

  • Designed for open baffle
  • High flow venting center pole
  • 3" CCAW voice coil
  • Low dampening surround
  • Non-inductive voice coil former
  • Proprietary cone materials made-in-house
  • Cast Aluminium chassis



Product details

SB Acoustics SB34NRX75-16 12" Woofer



The SB Acoustics SB34NRX75-16 12" woofer uses a large 3" voice coil on a cast aluminium chassis. Hard Paper proprietary cone materials made in-house for consistency. Low damping SBR rubber surround with high exertion and resilience. Open structure cast frame for reduced reflections and compression. Aluminium alloy for light weight, non-magnetic and extra rigidity. Shorting Copper cap on pole piece. Non-inductive 75mm coil former. Especially designed for open baffle designs but also works well in large sealed enclosures.

Eigenschaften

Artikelnummer:
SB34NRX75-16
Woofer Series
NRX Series
Woofer Type
Woofer
Nominal Diameter
12 ''
Power Handling (RMS)
100 Watts
Power Handling (max)
200 Watts
Impedance
16 Ohms
Sensitivity
86 dB 2.83V/1m
Frequency Response
24-500 Hz
DC Resistance (Re)
14 Ohms
Voice Coil Inductance (Le)
3.2 mH
Resonant Frequency (Fs)
24.5 Hz
Mechanical Q (Qms)
6.52
Electromagnetic Q (Qes)
0.74
Total Q (Qts)
0.66
Diaphragm Mass Inc. Airload (Mms)
72 g
Mechanical Compliance of Suspension (Cms)
0.59
Surface Area of Cone (Sd)
508 cm2
BL Product (BL)
14.5 Tm
Compliance Equivalent Volume (Vas)
216 l
Maximum Linear Excursion (Xmax)
11 mm
Cone / Diaphragm Material
Hard coated paper
Surround Material
Rubber
Voice Coil Wire Material
Copper
Voice Coil Former
CCAW
Basket / Frame Material
Cast aluminum
Magnet Material
Ferrite
Overall Outside Diameter
346 mm
Overall Depth
156 mm
Baffle Cutout Diameter
305 mm
# Mounting Holes
8
Mounting Hole Diameter
5.5 mm
