- Artikelnummer:
- SB23MFCL45-4
- Woofer Type
- Subwoofer
- Nominal Diameter
- 8''
- Power Handling (RMS)
- 150 Watts
- Impedance
- 4 Ohms
- Sensitivity
- 87.4 dB(2.83V/1m)
- Voice Coil Diameter
- 45.5 mm
- Magnet Weight
- 2.0 kg
- DC Resistance (Re)
- 3.3 Ohms
- Voice Coil Inductance (Le)
- 0.73 mH
- Resonant Frequency (Fs)
- 27 Hz
- Mechanical Q (Qms)
- 7.7
- Electromagnetic Q (Qes)
- 0.36
- Total Q (Qts)
- 0.34
- Diaphragm Mass Inc. Airload (Mms)
- 59 g
- Mechanical Compliance of Suspension (Cms)
- 0.59 mm/N
- Surface Area of Cone (Sd)
- 210 cm2
- BL Product (BL)
- 9.6 Tm
- Compliance Equivalent Volume (Vas)
- 37 Ltr
- Maximum Linear Excursion (Xmax)
- 24 mm (p-p)
- Driver's Mechanical Losses (Rms)
- 1.3 kg/s
- Cone / Diaphragm Material
- Polypropylene
- Surround Material
- Rubber
- Voice Coil Wire Material
- Copper
- Voice Coil Former
- Fibre glass
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 234 mm
- Overall Depth
- 122.1
- Baffle Cutout Diameter
- 203 mm
- # Mounting Holes
- 8
