Peerless by Tymphany XLS-P830452 10" XLS Subwoofer

€ 146,49€ 177,25 2 Auf Lager: Lieferzeit 1-3 Werktage
This series of state-of-the-art subwoofers continues to enhance Peerless's reputation for delivering the highest quality components for bass.... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €168,39 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

This series of state-of-the-art subwoofers continues to enhance Peerless's reputation for delivering the highest quality components for bass.



Highlights

  • 12.5 mm of linear excursion
  • Thick Nomex cone
  • Cast aluminum frame
  • Flat spider and HD rubber half roll surround
  • Massive stacked magnet



Product details

Peerless by Tymphany XLS-P830452 10" XLS Subwoofer



This 10 inch 4 ohm member of the XLS product family has all the design features suitable for a high performance subwoofer driver. The motor features a double ferrite magnet motor, supporting high excursion, and aluminium shorting rings and pole extenders, lowering and linearizing the inductance of the overhung voice coil. The nomex cone is vented under the dust cap, to reduce air compression. The suspension system features a low-creep rubber surround, and a nomex spider, ensuring long-term reliability under high power conditions. The product also features a rigid cast aluminium basket.

Eigenschaften

Artikelnummer:
XLS-P830452
Woofer Series
XLS Series
Woofer Type
Subwoofer
Nominal Diameter
10"
Power Handling (RMS)
150 Watts
Power Handling (max)
300 Watts
Impedance
4 ohms
Sensitivity
86.6 dB 2.83V/1m
Frequency Response
19 to 700Hz
Voice Coil Diameter
2"
DC Resistance (Re)
3.6 ohms
Voice Coil Inductance (Le)
0.99 mH
Resonant Frequency (Fs)
22 Hz
Mechanical Q (Qms)
3.86
Electromagnetic Q (Qes)
0.24
Total Q (Qts)
0.23
Diaphragm Mass Inc. Airload (Mms)
136.6g
Mechanical Compliance of Suspension (Cms)
0.39 mm/N
Surface Area of Cone (Sd)
349.7 cm²
BL Product (BL)
16.75 Tm
Compliance Equivalent Volume (Vas)
2.36 ft.³
Maximum Linear Excursion (Xmax)
12.5 mm
Cone / Diaphragm Material
Paper
Surround Material
Rubber
Basket / Frame Material
Cast Aluminum
Magnet Material
Ferrite
Overall Outside Diameter
10.59"
Overall Depth
4.88"
Baffle Cutout Diameter
9.4"
# Mounting Holes
6
Sealed Volume
0.12 ft.³
Sealed F3
95 Hz
Vented Volume
0.24 ft.³
Vented F3
65 Hz

Bewertungen

5 from 5Based on 4 reviews
Produkt bewerten
5 van 5
Owned one before and tested it limits. It handled almost 1000w rms in 18l sealed box before lower suspension gave up. Tested many similiar subwoofers in car installations but came back to this subwoofer. Very good integration, linear response and neutral sound. Works very well in small sealed box. Works in car and home audio setups. Good quality-price ratio.
Durch Toni M. on 13 November 2020
5 van 5
Goede sub voor deze prijs
Durch Theo G. on 4 Februar 2020
