- Artikelnummer:
- SLS-P830946
- Woofer Type
- Woofer
- Nominal Diameter
- 6-1/2"
- Power Handling (RMS)
- 75 Watts
- Power Handling (max)
- 150 Watts
- Impedance
- 4 ohms
- Sensitivity
- 82 dB 2.83V/1m
- Frequency Response
- 20 to 1,000Hz
- Voice Coil Diameter
- 1.5"
- DC Resistance (Re)
- 2.71 ohms
- Voice Coil Inductance (Le)
- 0.65 mH
- Resonant Frequency (Fs)
- 42 Hz
- Mechanical Q (Qms)
- 4.92
- Electromagnetic Q (Qes)
- 0.38
- Total Q (Qts)
- 0.35
- Diaphragm Mass Inc. Airload (Mms)
- 30.5g
- Mechanical Compliance of Suspension (Cms)
- 0.47 mm/N
- Surface Area of Cone (Sd)
- 123.5 cm²
- BL Product (BL)
- 7.6 Tm
- Compliance Equivalent Volume (Vas)
- 0.4 ft.³
- Maximum Linear Excursion (Xmax)
- 8.2 mm
- Cone / Diaphragm Material
- Paper
- Surround Material
- Rubber
- Basket / Frame Material
- Steel
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 7.165"
- Overall Depth
- 3.28"
- Baffle Cutout Diameter
- 5.79"
- # Mounting Holes
- 6
- Sealed Volume
- 0.09 ft.³
- Sealed F3
- 95 Hz
- Vented Volume
- 0.21 ft.³
- Vented F3
- 55 Hz
