- Artikelnummer:
- SDS-P830855
- Woofer Series
- SDS Series
- Woofer Type
- Subwoofer
- Nominal Diameter
- 8”
- Power Handling (RMS)
- 30 Watts
- Power Handling (max)
- 60 Watts
- Impedance
- 8 Ohms
- Sensitivity
- 84.8 dB 2.83V/1m
- Frequency Response
- 63 to 6,200Hz
- Voice Coil Diameter
- 1"
- DC Resistance (Re)
- 5.6 ohms
- Voice Coil Inductance (Le)
- 0.24 mH
- Resonant Frequency (Fs)
- 63 Hz
- Mechanical Q (Qms)
- 4.66
- Electromagnetic Q (Qes)
- 0.49
- Total Q (Qts)
- 0.44
- Diaphragm Mass Inc. Airload (Mms)
- 6.9g
- Mechanical Compliance of Suspension (Cms)
- 0.923 mm/N
- Surface Area of Cone (Sd)
- 50.3 cm²
- BL Product (BL)
- 5.58 Tm
- Compliance Equivalent Volume (Vas)
- 0.11 ft.³
- Maximum Linear Excursion (Xmax)
- 3 mm
- Cone / Diaphragm Material
- Treated Paper
- Surround Material
- Rubber
- Basket / Frame Material
- Steel
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 4.85"
- Overall Depth
- 3.64"
- Baffle Cutout Diameter
- 3.75"
- # Mounting Holes
- 6
- Sealed Volume
- 0.04 ft.³
- Sealed F3
- 113 Hz
- Vented Volume
- 0.125 ft.³
- Vented F3
- 58 Hz
