- Artikelnummer:
- SDS-P830656
- Woofer Series
- SDS Series
- Woofer Type
- Midwoofer
- Nominal Diameter
- 5-1/4”
- Power Handling (RMS)
- 60 Watts
- Power Handling (max)
- 110 Watts
- Impedance
- 8 Ohms
- Sensitivity
- 84.5 dB 2.83V/1m
- Frequency Response
- 50 to 5,000Hz
- Voice Coil Diameter
- 1"
- DC Resistance (Re)
- 6.1 ohms
- Voice Coil Inductance (Le)
- 0.37 mH
- Resonant Frequency (Fs)
- 57 Hz
- Mechanical Q (Qms)
- 3.6
- Electromagnetic Q (Qes)
- 0.7
- Total Q (Qts)
- 0.59
- Diaphragm Mass Inc. Airload (Mms)
- 9.3g
- Mechanical Compliance of Suspension (Cms)
- 0.83 mm/N
- Surface Area of Cone (Sd)
- 86.6 cm²
- BL Product (BL)
- 5.36 Tm
- Compliance Equivalent Volume (Vas)
- 0.31 ft.³
- Maximum Linear Excursion (Xmax)
- 3.46 mm
- Cone / Diaphragm Material
- Coated Paper
- Surround Material
- Rubber
- Basket / Frame Material
- Steel
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 5.98"
- Overall Depth
- 2.23"
- Baffle Cutout Diameter
- 4.61"
- # Mounting Holes
- 6
- Sealed Volume
- 0.2 ft.³
- Sealed F3
- 99 Hz
- Vented Volume
- 0.58 ft.³
- Vented F3
- 48 Hz
