Morel TiCW 1058Ft Titanium Series 10" Subwoofer 8 Ohm

€ 469,95 1 Auf Lager: Lieferzeit 1-3 Werktage
To create their Titanium Ultimate high fidelity 10" subwoofer, Morel began with an extra-large, 5.1" diameter, Hexatech™ aluminum voice coil wound on a vented titanium former.... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €446,45 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

Morel applied their years of experience and creative genius to produce a world-beating sub-bass driver…the Titanium Ultimate 10" subwoofer. Get a free knock-down subwoofer cabinet for a limited time with the purchase of a Morel Titanium Ultimate 10" subwoofer.



Highlights

  • Copper-sleeved pole piece and titanium former reduce speed-depleting inductance
  • 8 ohm impedance for a high damping factor and more amplifier control
  • 5.1" Hexatech voice coil for 600 watts RMS power handling
  • Accucenter self-centering, one-piece paper cone assembly



Product details

Morel TiCW 1058Ft Titanium Series 10" Subwoofer 8 Ohm



To create their Titanium Ultimate high fidelity 10" subwoofer, Morel began with an extra-large, 5.1" diameter, Hexatech™ aluminum voice coil wound on a vented titanium former. Moving this beast requires huge amounts of magnetic force, so to do so Morel uses a high flux double magnet system.



Speed-robbing energy storage is reduced to an insanely low 0.52 mH through the combination of the titanium former and a copper-sleeved pole piece. Trapped air within the subwoofer is virtually inexistent due to the Uniflow™ cast aluminum chassis, which works with the Accucenter™ self-centering cone assembly to reduce distortion and the effects of power compression.



For a limited time, a 1.25 cubic foot knock-down subwoofer cabinet is included for free. This cabinet creates a critically damped system when used with the Morel Titanium Ultimate 10" subwoofer and 1 lb. of Acousta-Stuf, for a Qtc of 0.61 and an f6 of 38 Hz, for refined sub-bass playback that excels with classical, jazz, and high-fidelity recordings.

Eigenschaften

Artikelnummer:
TiCW 1058Ft
Woofer Series
Titanium Series
Woofer Type
Subwoofer
Nominal Diameter
10"
Power Handling (RMS)
600 Watts
Power Handling (max)
3,000 Watts
Impedance
8 ohms
Sensitivity
86 dB 2.83V/1m
Frequency Response
24 to 2,000 Hz
Voice Coil Diameter
5.1"
DC Resistance (Re)
6.3 ohms
Voice Coil Inductance (Le)
0.52 mH
Resonant Frequency (Fs)
24 Hz
Mechanical Q (Qms)
4.95
Electromagnetic Q (Qes)
0.40
Total Q (Qts)
0.37
Diaphragm Mass Inc. Airload (Mms)
106 g
Mechanical Compliance of Suspension (Cms)
0.48 mm/N
Surface Area of Cone (Sd)
346 cm²
BL Product (BL)
15.86 Tm
Compliance Equivalent Volume (Vas)
3.74 ft.³
Maximum Linear Excursion (Xmax)
10.5 mm
Cone / Diaphragm Material
Paper
Surround Material
Rubber
Voice Coil Wire Material
Aluminum
Voice Coil Former
Titanium
Basket / Frame Material
Cast Aluminum
Magnet Material
Ferrite
Overall Outside Diameter
10.35"
Overall Depth
5.85"
Baffle Cutout Diameter
9.49"
# Mounting Holes
6
Mounting Hole Diameter
5 mm
Sealed Volume
1.04 ft.³
Sealed F3
51 Hz
Vented Volume
2.38 ft.³
Vented F3
29 Hz
