Monacor SPH-220HQ 8'' High-End Woofer

€ 74,34€ 89,95 Nicht auf Lager: Lieferzeit beträgt 3 Werktage
High-end woofer a coated paper cone. A very broad frequency response makes it suitable for almost any application... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €85,45 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

High-end woofer a coated paper cone. A very broad frequency response makes it suitable for almost any application.



Highlights

  • High-quality coated paper cone of low resonance
  • Long excursion
  • Extremely broad frequency range



Product details

Monacor SPH-220HQ 8'' High-End Woofer

The Monacor SPH-220HQ is a further development of the classic SPH-212 speaker. It features a rear-ventilated centering spider and drilled pole core for minimum mechanical loss, a low resonance high-quality coated paper cone and a low-loss rubber surround. The clever design of this woofers ensures a wide and linear radiation range, ideally suited for 3-way systems and also suitable for traditional 2-way systems in an application range of up to 2,500 Hz and beyond.

Eigenschaften

Artikelnummer:
SPH-220HQ
Woofer Type
Woofer
Nominal Diameter
8''
Power Handling (RMS)
100 Watts
Power Handling (max)
180 Watts
Impedance
8 Ohms
Sensitivity
90 dB 1W/m
Frequency Response
30-4,000hz
Voice Coil Diameter
37 mm
Magnet Weight
550 g
DC Resistance (Re)
6.1 Ohms
Voice Coil Inductance (Le)
0.9 mH
Resonant Frequency (Fs)
30 Hz
Mechanical Q (Qms)
3.06
Electromagnetic Q (Qes)
0.46
Total Q (Qts)
0.40
Diaphragm Mass Inc. Airload (Mms)
24.7 g
Mechanical Compliance of Suspension (Cms)
1.06 mm/N
Surface Area of Cone (Sd)
232 cm2
BL Product (BL)
7.63 Tm
Compliance Equivalent Volume (Vas)
80 l
Maximum Linear Excursion (Xmax)
5.5 mm
Cone / Diaphragm Material
Coated Paper
Surround Material
Rubber
Voice Coil Wire Material
Copper
Voice Coil Former
aluminium
Basket / Frame Material
Aluminum
Magnet Material
Ferrite
Overall Outside Diameter
222 mm
Overall Depth
94 mm
# Mounting Holes
6
Mounting Hole Diameter
5.3mm

Bewertungen

5 from 5Based on 1 reviews
Produkt bewerten
5 van 5
Used Monacor brand before. A very high quality speaker. Sure, you may find cheaper products, but they'll sound cheaper too! Would definitely use again. Sound imports are competitive, and efficient. Nice one guys!
Durch Scott V. on 18 Februar 2020
