miniDSP PWR-ICE250 2x250 Watt DSP ICEpower Plate Amplifier

€ 409,88€ 495,95 7 Auf Lager: Lieferzeit 1-3 Werktage
2x250W @ 4Ω or 1 x 500W @ 8Ω DSP plate amplifier, Powered by ICEpower® 250ASX2 module, Ethernet control, FIR + IIR filter... Mehr anzeigen
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

2x250W @ 4Ω or 1 x 500W @ 8Ω DSP plate amplifier, Powered by ICEpower® 250ASX2 module, Ethernet control, FIR + IIR filter



Highlights

  • DSP Powered plate amplifier with FIR + IIR filters
  • Powered by ICEpower® technology for 2x250W @ 4Ω or 1 x 500W @ 8Ω
  • Windows & Mac compatible, IP control over Ethernet/Wifi
  • Analog & Digital input
  • Multi-unit control via Ethernet
  • Perfect fit for 2way active speakers or Subwoofer plate amplifier



Product details

PWR-ICE250 2 x 250 Watt DSP ICEpower Plate Amplifier

Note: This product comes with a coupon (€9,50) for one free miniDSP plugin download.

Introducing the PWR-ICE250, a DSP powered plate amplifier module for active 2 way loudspeakers or mono subwoofers. Result of the collaborative effort of two innovative technology companies, the PWR-ICE250 core features include:

  • On the processing side is miniDSP's innovative software & firmware allowing a Plug & Play real time control of the onboard DSP over Ethernet/Wifi networks. Using our Zero Conf technology, multiple modules are automatically discovered and controlled from a single User interface in real time. The platform is supported under Mac and Windows environment.The onboard Digital Signal Processors (DSP) provide real time all the processing a speaker designers will expect to excel at his crossover design task. These include FIR + IIR filters, Parametric Equalizers (PEQ), Level, crossovers, comp/limiter, delay and more. The Graphical User Interface (GUI) platform is supported on both Mac and Windows environment.
  • On the power amplifier side, the ICEpower® 250ASX2 modules are complete AC plug-to-speaker amplification audio solutions offering flexible two-channel or bridgeable speaker drive. Their compact size, audiophile audio quality and high power output make them perfect for high-performing audio products. The amplifier is rated for up to 2x250W @ 4Ω or 1 x 500W @ 8Ω

As for audio connectivity, the PWR-ICE250 is fitted with both analog balanced (XLR) & unbalanced inputs (RCA) to provide maximum compatibility. A digital input (AES-EBU/SPDIF) saves on the A-D conversion for maximum performance while a Digital output (AES-EBU/SPDIF) allows multiple plate amplifiers to be linked to each other.



What's in the box?

  • 1 x PWR-ICE250 amplifier module
  • 1 x CAT5 patch cable
  • 1 x IEC power cord
  • 4 x black wood screws for mounting
  • 1 x Speaker wire harness to connect amplifier to speaker (60cm long)
  • 1 x Coupon code for miniDSP plugin download



System Diagram



Mechanical Specifications



Eigenschaften

Artikelnummer:
PWR-ICE250
Rated power output
2 x 230 watts at 4 ohms
Bridged rated power output (RMS)
1 x 500 watts at 8 ohms
Minimum load
3 ohms
Signal-to-noise ratio (SNR)
-
Distortion
0.008 % THD+N (100 Hz at 1 watt)
Distortion bridged
0.004 % THD+N (100 Hz at 1 watt)
Amplifier classification
Class D
Circuit topology
ICEpower
Efficiency
76.3 % at full power
Frequency response
20 - 20,000 Hz
Input impedance

10k ohms (unbalanced)
47k ohms (balanced)

Input sensitivity

1/2 Vrms (unbalanced)
2/8 Vrms (unbalanced)

Auto turn-on sensitivity
-
DSP
check
DAC
check
Maximum sampling rate
96 kHz
Speaker output channels
2
Analog in/out
1/-
S/PDIF in/out
-/-
AES/EBU in/out
1/1
Coaxial in/out
-/-
XLR in/out
2/1
Jack in/out
-/-
USB connection
-
Network connection
check
Bluetooth
-
Subwoofer pre-out
-
Auto on/off
-
Remote control
-
App control
check
Equalizer (EQ) adjustment
check
Equalizer (EQ) profiles
check
Phase control
check
Crossover frequency adjustment
check
Presets
check
Control software
miniDSP plugin
Windows/Mac compatible
check/check
Power requirements
110 / 240 VAC
Power inlet connector
IEC C14
Standby power consumption
-
Current limit
30 A
Under/over voltage protection
-
Dimensions (H x W x D)
267.5 x 153 x 77 mm
Cutout dimensions
253 x 139 mm

Bewertungen

5 from 5Based on 1 reviews
Produkt bewerten
5 van 5
Great tool, easy to integrate, with comprehensive features. Possibility of full stereo 2CH operation or bridged mono mode, which is not common to similar competitor's modules (e.g. limitation to low/high 2way by design etc.)
Durch Viktor S. on 9 April 2020
