HiVi F10 10" Woofer

€ 95,-€ 114,95 1 Auf Lager: Lieferzeit 1-3 Werktage
The HiVi F10's design has been optimized for dynamic low bass performance in a compact or medium size vented enclosure.... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €109,20 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

The HiVi F10's design has been optimized for dynamic low bass performance in a compact or medium size vented enclosure.



Highlights

  • Light and extremely rigid cone made from Kevlar/paper composite
  • High loss rubber surround
  • High power handling polyimide former voice coil
  • Long-throw motor system with extended linear excursion capability
  • High-density aluminum die-cast basket



Product details

HiVi F10 10" Woofer



The HiVi F10's design has been optimized for dynamic low bass performance in a compact or medium size vented enclosure. The F10 utilizes a newly developed matrix of Kevlar and paper fibers. The cone weighs less, is more rigid, and has an improved damping factor. It keeps distortion very low through the woofer's wide frequency and power range. The driver has a vented pole piece to avoid air compression and ensure maximum power handling. The long-throw design provides clean and articulate bass performance at high volumes. A massive aluminum die-cast basket has been developed to minimize structural resonances. Recommended crossover frequency, 300Hz.

Eigenschaften

Artikelnummer:
F10
Woofer Type
Midwoofer
Nominal Diameter
10"
Power Handling (RMS)
100 Watts
Power Handling (max)
200 Watts
Impedance
8 ohms
Sensitivity
89 dB 2.83V/1m
Frequency Response
28 to 3,000 Hz
Voice Coil Diameter
2"
DC Resistance (Re)
6.5 ohms
Resonant Frequency (Fs)
28 Hz
Mechanical Q (Qms)
5.12
Electromagnetic Q (Qes)
0.33
Total Q (Qts)
0.31
Diaphragm Mass Inc. Airload (Mms)
72.6g
Mechanical Compliance of Suspension (Cms)
0.42 mm/N
Surface Area of Cone (Sd)
363 cm²
BL Product (BL)
16.2 Tm
Compliance Equivalent Volume (Vas)
2.78 ft.³
Maximum Linear Excursion (Xmax)
6 mm
Cone / Diaphragm Material
Paper / Kevlar
Surround Material
Rubber
Voice Coil Former
Kapton® / Polyimide
Dual Voice Coil
No
Basket / Frame Material
Cast Aluminum
Magnet Material
Ferrite
Shielded
Yes
Overall Outside Diameter
11.26"
Overall Depth
4.41"
Baffle Cutout Diameter
9.29"
# Mounting Holes
12
Sealed Volume
0.43 ft.³
Sealed F3
77 Hz
Vented Volume
0.99 ft.³
Vented F3
48 Hz
