      Ultimax UM15-22 Subwoofer Tieftöner

      Ultimax UM15-22 Subwoofer Tieftöner

      €369,95

      Zum Warenkorb hinzufügen

      Dayton Audio Ultimax UM15-22 Subwoofer Tieftöner

      9 reviews
      5 von 5
      9 reviews
      5 Sterne
      89%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      11%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      Marke: Dayton Audio
      Zeige alle Subwoofer
      15" | 2+2 Ω
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      305,74 €369,95 € Nicht auf Lager10+ erwartet auf 31-05-2024
      • -5% Bestelle 4 für nur € 351,45 je Stück
      • -10% Bestelle 8 für nur € 332,96 je Stück
      +-
      Zum Warenkorb hinzufügen

      Buy now, pay later

      • Kostenloser Versand (DE & A)
      • Jetzt bestellt, morgen versandt
      • Fünf Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      Haben Sie eine Frage zu diesem Produkt?

      Haben Sie eine Frage zu diesem Produkt?

      Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner
      Ultimax UM15-22 Subwoofer Tieftöner

      Produktbeschreibung

      Dayton Audio's Ultimax Series DVC subwoofers are purpose-built to move air and create clean, articulate, fast bass. Experience the apex of subwoofer design.



      Highlights

      • Sweeps massive amounts of air!
      • Over 1-1/2" of total cone travel
      • 800 watts RMS power handling
      • The latest in subwoofer technology
      • Dual linear stiffness spiders limit distortion and rocking modes
      • Dual 2 ohm, 2-layer copper voice coils
      • Large vented pole piece and under-spider venting



      Product details

      Dayton Audio UM15-22 15" Ultimax DVC Subwoofer 2 ohms Per Coil



      If you want outrageous amounts of bass, you gotta move some air

      The Ultimax Series of dual voice coil subwoofers, from Dayton Audio, are not for the faint of heart. Built using the latest in subwoofer technology, Ultimax subwoofers are the pinnacle of low frequency driver design. An Ultimax subwoofer tests the strength of your foundation with fast, articulate, gut-wrenching bass.



      The versatility you need for mobile, home, or pro subwoofer excellence

      Dual 2 ohm voice coils allow for stereo 2 ohm and mono 1 ohm wiring configurations when connecting to high current car audio and professional audio amplifiers to extract maximum power. For home audio applications, simply wire the voice coils in series for a benign 4 ohm load for greater amplifier compatibility.



      Built to produce massive low frequency output and keep on doing it

      To improve power handling, increase thermal management, and reduce power compression, Dayton Audio designed the Ultimax Series with large black anodized formers and vented pole pieces, under-spider ventilation, and two-layer copper voice coils.



      Over 1-1/2" of travel (3/4" Xmax) is kept completely linear through the use of dual spiders that also limit distortion and rocking modes. "Tall-boy" rubber surrounds with integrated gaskets maintain driver surface area during extreme excursion moments. Thick, one-piece Nomex honeycomb covered cones are covered with woven, heavy-duty glass fibers creating ultra-still cones that resist deformation.



      A strong motor takes you to wherever you want to be

      A large copper sleeve and copper pole cap in the motor reduce energy storage from inductance, with the side benefit of lowering distortion for "faster" response. Large dual-stacked, high-energy magnets handle the heavy lifting and bring Qts down to a level where Ultimax subwoofers can be used in vented or sealed cabinets and enclosures.

      Cabinet recommendations:

      • Sealed: 3.8 cubic ft. (net internal, not including driver volume) with 3 lbs. of Acousta-Stuf polyfill produces an f3 of 34 Hz with a 0.83 Qtc alignment
      • Vented: 4.5 cubic ft. (net internal, not including driver or port volume) produces an f3 of 24 Hz. Larger cabinets and lower tuning frequencies are possible.



      Note: All parameters derived with voice coils wired in series.

      Mehr anzeigen

      Eigenschaften

      Artikelnummer:
      UM15-22
      Tieftöner-Serie
      Ultimax Series
      Tieftönertyp
      Subwoofer
      Belastbarkeit (QMW)
      800 watts
      Belastbarkeit (max)
      1,600 watts
      Impedanz (Z)
      4 ohms
      Empfindlichkeit (SPL bei 1m / 2,83V)
      86.5 dB
      Frequenzgang
      15 - 1,000 Hz
      Schwingspulendurchmesser
      63.5 mm
      Gleichstromwiderstand (Re)
      3.7Ω
      Schwingspuleninduktion (Le)
      0.8mH
      Resonanzfrequenz (Fs)
      28.4Hz
      Mechanische Güte (Qms)
      2.8
      Elektrische Güte (Qes)
      0.95
      Gesamtgüte (Qts)
      0.71
      Bewegliche Masse (Mms)
      287g
      Nachgiebigkeit der Aufhängung (Cms)
      0.11mm/N
      Membranfläche (Sd)
      814.6 cm²
      Verschiebevolumen (Vd)
      1,548 cm³
      Kraftfaktor (BL)
      14.1T·m
      Äquivalentvolumen (Vas)
      101.94 liters
      Maximale Auslenkung (Xmax)
      19 mm
      Cone / Diaphragm Material
      Nomex Cone
      Sicke-Material
      Rubber
      Schwingspulendrahtmaterial
      Copper
      Schwingspulenformmaterial
      Aluminum
      Dual Voice Coil
      Yes
      Korb- / Rahmenmaterial
      Cast Aluminum
      Magnetmaterial
      Ferrite
      Außendurchmesser
      388 mm
      Gesamttiefe
      226 mm
      Ausschnittdurchmesser
      350 mm
      Bolt Circle Diameter
      14.76
      # Befestigungsbohrungen
      8
      Geschlossenes Volumen
      3.1 cubic ft. (net internal) with 3 lbs. of Acousta-Stuf polyfill
      Geschlossenes F3
      35 Hz with a 0.707 Qtc alignment
      Bassreflex Volumen
      6.0 cubic ft. (net internal, not including driver or port volume) with 6 lbs. of Acousta-Stuf tuned to 18 Hz with two 4" diameter by 26" long flared ports
      Bassreflex F3
      22 Hz. Larger cabinets and lower tuning frequencies are possible.

      Mehr anzeigen

      Bewertungen

      9 reviews
      Produkt bewerten
      5 von 5
      Aivan mahtava sq käytössä autossa 125l suljetussa
      Durch Tero on 29 März 2023
      5 von 5
      This is a very, very well built woofer who delivers exactly what it says! Oddly there is no exaggeration in the selling text, And it delivers more. Built towers 40 by 40 cm and 1,2M high wit 2x4"x66cm vents. and it is digging very, very deep in the octaves. It was almost hard to beleive the room analyzer :D going down to 16Hz and feeling it all the way. I have built woofers for 35+ years and this must be the (for the money) best of them! Thanks S...

      Mehr anzeigen

      Durch Andreas Karlsson on 18 Juli 2022
      Mehr anzeigen
