Dayton Audio RSS265HF-4 10" Reference HF Subwoofer 4 Ohm

€ 186,25 3 Auf Lager: Lieferzeit 1-3 Werktage
The Dayton Audio RSS265HF-4 10" subwoofer features the high-definition/low-distortion attributes of the acclaimed Reference Series, and provides great results in compact single-driver subwoofer speaker systems...or when used in multiples!... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €176,94 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

The Dayton Audio RSS265HF-4 10" subwoofer features the high-definition/low-distortion attributes of the acclaimed Reference Series, and provides great results in compact single-driver subwoofer speaker systems...or when used in multiples!



Highlights

  • Extensively vented motor eliminates compression and allows quiet excursion
  • Lightweight black anodized aluminum cone for rigidity and lower moving mass
  • Suitable for sealed or vented enclosures
  • Triple shorting ring motor for ultra-low distortion
  • 2-layer coil for reduced back EMF
  • Highest quality materials throughout for long-lasting performance



Product details

Dayton Audio RSS265HF-4 10" Reference HF Subwoofer 4 Ohm



As with the rest of the Reference Series, the main focus of the Dayton Audio RSS265HF 10" subwoofer is ultra-low distortion. Second, third, and intermodulation distortion are kept extremely low by utilizing three short-circuit paths within the motor structure. A durable aramid fiber spider and extensive venting throughout provide quiet and uniform excursion. The black anodized cone, thick rubber surround, and custom basket give this Dayton Audio driver a unique, high-end look. Choose the High Fidelity (HF) version for home systems when you are looking for clean, low bass and are not restricted by speaker cabinet size.



Eigenschaften

Artikelnummer:
RSS265HF-4
Woofer Series
Reference Series
Woofer Type
Subwoofer
Nominal Diameter
10"
Power Handling (RMS)
350 watts
Power Handling (max)
700 watts
Impedance
4 ohms
Sensitivity
87.8 dB @ 2.83V/1m
Frequency Response
22 - 1,000 Hz
Voice Coil Diameter
64 mm
Magnet Weight
100 oz.
DC Resistance (Re)
3.5 ohms
Voice Coil Inductance (Le)
0.96 mH @ 1 kHz
Resonant Frequency (Fs)
25.6 Hz
Mechanical Q (Qms)
3.06
Electromagnetic Q (Qes)
0.53
Total Q (Qts)
0.45
Diaphragm Mass Inc. Airload (Mms)
120g
Mechanical Compliance of Suspension (Cms)
0.32 mm/N
Surface Area of Cone (Sd)
356.3 cm²
Volume of Displacement (Vd)
438.3 cm³
BL Product (BL)
11.43 Tm
Compliance Equivalent Volume (Vas)
54 liters
Maximum Linear Excursion (Xmax)
12.3 mm
Cone / Diaphragm Material
Black Anodized Aluminum Cone
Surround Material
Rubber
Voice Coil Wire Material
Copper
Voice Coil Former
Aluminum
Basket / Frame Material
Steel
Magnet Material
Ferrite
Overall Outside Diameter
266 mm
Overall Depth
136.5 mm
Baffle Cutout Diameter
235 mm
# Mounting Holes
6
Sealed Volume
0.53 ft.³
Sealed F3
51 Hz
Vented Volume
1.68 ft.³
Vented F3
27 Hz
