Dayton Audio RS75T-8 3" Reference Full-Range Driver Truncated Frame

€ 29,95 >10 Auf Lager: Lieferzeit 1-3 Werktage
Incorporating a low-distortion motor system with a copper ring, a copper cap, and an aluminum phase plug, the RS75T-8 can outperform "boutique" drivers that cost several times the price.... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €28,45 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

Incorporating a low-distortion motor system with a copper ring, a copper cap, and an aluminum phase plug, the RS75T-8 can outperform "boutique" drivers that cost several times the price.



Highlights

  • Truncated cast frame—great for line arrays and MTM speaker designs
  • Full-range performance
  • Low distortion and high resolution
  • Aluminum frame, aluminum cone, rubber surround
  • Distortion-reducing copper ring, copper cap, and aluminum phase plug
  • Subtle yet high-tech look makes a bold cosmetic statement
  • Designed and engineered in USA



Product details

Dayton Audio RS75T-8 3" Reference Full-Range Driver Truncated Frame



The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker drivers. Incorporating a low-distortion motor system with a copper ring, a copper cap, and an aluminum phase plug, the RS75T-8 can outperform "boutique" drivers that cost several times the price. The driver's truncated frame makes it ideal for line arrays and ultra-compact MTM designs requiring minimal driver-to-driver spacing. Its low-distortion characteristics and smooth response provide exceptional clarity, detail, and dynamics. Features a black anodized cone, heavy-duty 4-hole cast frame, low-loss rubber surround, and gold terminals.

Eigenschaften

Artikelnummer:
RS75T-8
Woofer Series
Reference Series
Woofer Type
Full-Range
Nominal Diameter
3"
Power Handling (RMS)
15 watts
Power Handling (max)
30 watts
Impedance
8 ohms
Sensitivity
84.3 dB @ 2.83V/1m
Frequency Response
170 - 20,000 Hz
Voice Coil Diameter
16 mm
DC Resistance (Re)
6.1 ohms
Voice Coil Inductance (Le)
0.32 mH @ 1 kHz
Resonant Frequency (Fs)
189 Hz
Mechanical Q (Qms)
5.84
Electromagnetic Q (Qes)
1.13
Total Q (Qts)
0.95
Diaphragm Mass Inc. Airload (Mms)
1g
Mechanical Compliance of Suspension (Cms)
0.69 mm/N
Surface Area of Cone (Sd)
12 cm²
Volume of Displacement (Vd)
1.56 cm³
BL Product (BL)
2.58 Tm
Compliance Equivalent Volume (Vas)
0.22 liters
Maximum Linear Excursion (Xmax)
1.3 mm
Cone / Diaphragm Material
Black Anodized Aluminum Cone
Surround Material
Rubber
Voice Coil Wire Material
Copper
Voice Coil Former
Aluminum
Basket / Frame Material
Cast Aluminum
Magnet Material
Ferrite
Overall Outside Diameter
72 mm
Overall Depth
38.5 mm
Baffle Cutout Diameter
54 mm
# Mounting Holes
4
Sealed Volume
0.02 ft.³
Sealed F3
175.2 Hz
Vented Volume
0.05 ft.³
Vented F3
96 Hz
