Dayton Audio RS180-8 7" Reference Woofer

Marke: Dayton Audio

Alle anzeigen Audio-Komponenten

Vergleichen

7" | 8 Ω

€ 59,95 4 Auf Lager: Lieferzeit 1-3 Werktage

Dayton Audio Reference Series RS180-8 7" woofers deliver exceptional clarity, detail, and dynamics--and of course, incredibly low distortion.... Mehr anzeigen

Versicherter Versand mit Sendungsverfolgung
Kostenloser Versand ab 149€ (DE, A)
Versand am selben Tag*
Hausinterner technischer Support

Produktbeschreibung

Dayton Audio Reference Series RS180-8 7" woofers deliver exceptional clarity, detail, and dynamics--and of course, incredibly low distortion.

Highlights

One of the lowest distortion, highest resolution driver series available
Low-distortion high-excursion motor system with two short-circuit paths
Compliant suspension and rigid black anodized aluminum cone for strong bass performance
Heavy-duty 6-hole cast frame, low-loss rubber surround, and solid aluminum phase plug
Designed and engineered in the USA

Product details

Dayton Audio RS180-8 7" Reference Woofer

The Dayton Audio Reference Series was conceived with one goal in mind—low distortion. Each speaker was carefully designed and optimized to offer the highest performance with the lowest distortion levels. At the same time, by focusing on features that contribute to sound quality and eliminating unnecessary frills, the drivers offer value unparalleled in the industry. Dayton Audio Reference Series RS180-8 7" woofers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.

Eigenschaften

Artikelnummer:: RS180-8
Woofer Series: Reference Series
Woofer Type: Midwoofer
Nominal Diameter: 7"
Power Handling (RMS): 60 watts
Power Handling (max): 120 watts
Impedance: 8 ohms
Sensitivity: 87.1 dB @ 2.83V/1m
Frequency Response: 39 - 3,600 Hz
Voice Coil Diameter: 38 mm
DC Resistance (Re): 6.4 ohms
Voice Coil Inductance (Le): 0.73 mH @ 1 kHz
Resonant Frequency (Fs): 35.7 Hz
Mechanical Q (Qms): 1.22
Electromagnetic Q (Qes): 0.42
Total Q (Qts): 0.31
Diaphragm Mass Inc. Airload (Mms): 17.9g
Mechanical Compliance of Suspension (Cms): 1.12 mm/N
Surface Area of Cone (Sd): 124.7 cm²
Volume of Displacement (Vd): 74.8 cm³
BL Product (BL): 7.82 Tm
Compliance Equivalent Volume (Vas): 24.4 liters
Maximum Linear Excursion (Xmax): 6.0 mm
Cone / Diaphragm Material: Black Anodized Aluminum Cone
Surround Material: Rubber
Voice Coil Wire Material: Copper
Voice Coil Former: Aluminum
Basket / Frame Material: Cast Aluminum
Magnet Material: Ferrite
Overall Outside Diameter: 180.5 mm
Overall Depth: 81 mm
Baffle Cutout Diameter: 146 mm
# Mounting Holes: 6
Sealed Volume: 0.16 ft.³
Sealed F3: 98 Hz
Vented Volume: 0.43 ft.³
Vented F3: 56 Hz

Data sheet

Bewertungen

5 from 5Based on 1 reviews

Produkt bewerten

5 van 5

Bought this Mid as a Replacement. The Paper Cone Has a very smooth Sound. The Enclosure is Tuned to about 40 hz. Very detailed and punshy Bass and Exelent Vocals. Really Good Overall Value.

Delivery was Quick and without and Problems as usual. will definitely Order again.

Durch FND on 20 September 2020
