Dayton Audio ND25FA-4 1" Soft Dome Neodymium Tweeter

€ 13,95 >10 Auf Lager: Lieferzeit 1-3 Werktage
Dayton Audio's compact, ultra-smooth ND25FA-4 soft dome tweeter features excellent detail and high power handling. The small faceplate and neodymium motor make it easy to keep center-to-center distance to a minimum for improved off-axis response, and the... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €13,25 pro stück
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Bezahlung mit PayPal, Kreditkarte und mehr
  • Hausinterner technischer Support

Produktbeschreibung

Dayton Audio's compact, ultra-smooth ND25FA-4 soft dome tweeter features excellent detail and high power handling. The small faceplate and neodymium motor make it easy to keep center-to-center distance to a minimum for improved off-axis response, and the exceptionally flat response above 3 kHz.



Highlights

  • Exceptionally flat treble response with low distortion
  • Compact round faceplate design is simple to install
  • High-strength neodymium motor with heatsink and ferrofluid cooling
  • 1" diameter voice coil for good off-axis dispersion
  • Clean, modern styling and appearance



Product details

Dayton Audio ND25FA-4 1" Soft Dome Neodymium Tweeter



This tweeter is smooth! The Dayton Audio ND25FA-4 is a 1" soft-dome tweeter that combines an exceptionally flat response above 3 kHz with a compact round faceplate for a clean, modern appearance that integrates easily into any design. The tiny yet powerful neodymium motor structure features an aluminum heatsink and ferrofluid cooling for low power compression and improved long-term power handling. A copper pole cap within the motor further reduces distortion and inductance effects.



Choose the ND25FA-4 when you need detail that won't become fatiguing or shrill at high volumes, for a highly refined presentation. The compact faceplate allows for close center-to-center spacing of drivers, making these tweeters perfect for line array use or D'Appolito (MTM) configurations with wide dispersion.



Eigenschaften

Artikelnummer:
ND25FA-4
Tweeter Type
Soft Dome
Tweeter Series
ND Series
Cone / Dome Diameter
1"
Power Handling (RMS)
20 Watts
Impedance
4 ohms
Sensitivity
90 dB 2.83V/1m
Frequency Response
2,500 to 20,000 Hz
Resonant Frequency (Fs)
1,350 Hz
DC Resistance (Re)
3.20 ohms
Voice Coil Inductance (Le)
0.48 mH
Mechanical Q (Qms)
3.87
Electromagnetic Q (Qes)
2.61
Total Q (Qts)
1.56
Overall Outside Diameter
2.60"
Cutout Diameter
1.77"
Depth
1.00"

Bewertungen

4 from 5Based on 4 reviews
Produkt bewerten
5 van 5
I like to listen to beautiful music long ago, but the modest budget didn't allow to buy the high-quality speaker system. In my budget I didn't find acceptable quality in shop...
I long selected the project for independent production, and stopped on it: the author - Aleksey Aleksandrov from Orenburg.
I found woofers separately and bought other loudspeakers here.
After assembly of the speaker system I was delighted! The cleanest timbre and high detail of a sound! I listened to my favourite compositions and found in them a lot of new! I didn't expect such magnificence for such modest cost.
Durch Patuk Mihail Nikolaevich on 14 November 2018
4 van 5
Works perfectly and sounds good for the price, but has low efficiency and you have to be careful not to touch the cone because it's very sensitive.
Durch Michel R. on 17 September 2018
