Dayton Audio ND16FA-4 5/8" Soft Dome Neodymium Tweeter 4 Ohm

€ 10,45 >10 Auf Lager: Lieferzeit 1-3 Werktage
Dayton Audio's ND16FA-4 5/8" soft dome tweeter is perfect for use in compact 2-way systems such as desktop, surround, or portable speaker systems. With smooth response from 4,000 to 20,000 Hz this tweeter is ideal for adding more top end to many full-rang... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €9,93 pro stück
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Bezahlung mit PayPal, Kreditkarte und mehr
  • Hausinterner technischer Support

Produktbeschreibung

Dayton Audio's ND16FA-4 5/8" soft dome tweeter is perfect for use in compact 2-way systems such as desktop, surround, or portable speaker systems. With smooth response from 4,000 to 20,000 Hz this tweeter is ideal for adding more top end to many full-range drivers.



Highlights

  • Ferrofluid enhances power handling and helps damp resonance
  • Powerful neodymium motor keeps tweeter small with impressive efficiency
  • Compact faceplate is perfect for minimal center-to-center distances
  • Easy installation, front mount pressfit design



Product details

Dayton Audio ND16FA-4 5/8" Soft Dome Neodymium Tweeter 4 Ohm



The versatile ND16FA-4 5/8" soft dome tweeter from Dayton Audio has the sensitivity, smoothness, and power handling for use in a 2-way design with most small woofers. The compact faceplate allows minimal center-to-center distances making these a great choice for use in 2-way designs with high crossover points. With 4-ohm impedance, this tweeter is suitable for use in both home and automotive applications. Thanks to the Ferrofluid cooled voice coil, the ND13FA-4 can handle an impressive amount of power and has excellent damping for extremely accurate response.

Eigenschaften

Artikelnummer:
ND16FA-4
Tweeter Type
Soft Dome
Cone / Dome Diameter
5/8"
Power Handling (RMS)
30 Watts
Impedance
4 ohms
Sensitivity
93 dB 2.83V/1m
Frequency Response
4,000 to 20,000 Hz
Resonant Frequency (Fs)
2246 Hz
DC Resistance (Re)
3.17 ohms
Voice Coil Inductance (Le)
0.03 mH
Mechanical Q (Qms)
3.71
Electromagnetic Q (Qes)
3.46
Total Q (Qts)
1.79
Overall Outside Diameter
1.77"
Cutout Diameter
1.42"
Depth
0.45"

Bewertungen

4 from 5Based on 3 reviews
Produkt bewerten
5 van 5
Worked a treat fitted nicely into the design
Durch Malcocm C. on 21 Juli 2020
3 van 5
Prima tweeter voor het geld.
Durch Martin S. on 23 Juni 2020
