Dayton Audio DCS305-4 12" Classic Subwoofer 4 Ohm

Lieferzeit: 1-3 Werktage

  • Artikelnummer: DCS305-4
  • Vorrat: 5 Auf Lager

The Dayton Audio Classic Series subwoofers offer solid value at lower price points. No compromises were made in the design, materials, or construction of these rugged 4-ohm powerhouses.

€ 122,45 Inkl. MwSt.

  • Kaufen Sie 4 für je €116,33 und sparen Sie 5% Sale 5%

Auf den Wunschzettel

  • Gratis DHL-Versand ab 149€ (DE, A) Tooltip

    Bestellungen an Werktagen vor 16Uhr werden noch am selben Tag versandt. Weitere Informationen

  • Versand am selben Tag
  • 45 Tage Bedenkzeit
  • Zahlung mit Paypal/Kreditkarte

Produktbeschreibung

Dayton Audio DCS305-4 12" Classic Subwoofer 4 Ohm

The Dayton Audio Classic Series subwoofers offer solid value at lower price points. No compromises were made in the design, materials, or construction of these rugged 4-ohm powerhouses.



Highlights

  • Sturdy stamped steel frame
  • Vented pole piece and bumped back plate
  • Inductance-reducing copper pole piece cap
  • Treated non-pressed paper/Kevlar cone with rubber surround
  • 4-layer VC with polyimide former
  • Great for home and automotive applications



Product details

Dayton Audio DCS305-4 12" Classic Subwoofer 4 Ohm



The Dayton Audio Classic Series subwoofers offer solid value at lower price points. No compromises were made in the design, materials, or construction of these rugged 4-ohm powerhouses. The drivers feature a vented pole piece with copper cap, bumped back plate for improved excursion capability, Kevlar reinforced cone with rubber half-roll surround, and a high-temperature 4-layer copper voice coil wound on a polyimide former.

Eigenschaften

Spezifikationen für: DCS305-4 12" Classic Subwoofer 4 Ohm

  • Woofer Series Spezielle Woofer- Produktionsreihe des Herstellers. Classic Series
  • Woofer Type Art des Drivers, wie zum Beispiel, Subwoofer, Midwoofer, Full-range, Coaxial-Woofer Subwoofer
  • Nominal Diameter Ungefährer Durchmesser des Drivers, gemessen in Inch. 12"
  • Power Handling (RMS) Durchschnittliche elektrische Bestlastbarkeit eines Lautsprechers in Watt, ohne den Driver zu beschädigen. RMS = Root Mean Square steht für Root Mean Square. 250 watts
  • Power Handling (max) Die maximale kurzzeitige elektrische Belastbarkeit eines Lautsprechers in Watt, bevor es zu Schäden kommt. 500 watts
  • View all specifications
  • Continuous Program Power
  • Impedance 4 ohms
  • Sensitivity 90.5 dB @ 2.83VW/1m
  • Frequency Response 23 - 200 Hz
  • Voice Coil Diameter 65.5 mm
  • Magnet Weight
  • DC Resistance (Re) 3.3 ohms
  • Voice Coil Inductance (Le) 2.06 mH @ 1 kHz
  • Resonant Frequency (Fs) 24.2 Hz
  • Mechanical Q (Qms) 5.07
  • Electromagnetic Q (Qes) 0.43
  • Total Q (Qts) 0.40
  • Diaphragm Mass Inc. Airload (Mms) 160g
  • Moving Mass Of Diaphragm (Mmd)
  • Mechanical Compliance of Suspension (Cms) 0.27 mm/N
  • Surface Area of Cone (Sd) 498.8 cm²
  • Volume of Displacement (Vd) 468.8 cm³
  • BL Product (BL) 13.7 Tm
  • Compliance Equivalent Volume (Vas) 92.3 liters
  • Maximum Linear Excursion (Xmax) 9.3 mm
  • Driver's Mechanical Losses (Rms)
  • Cone / Diaphragm Material Paper / Kevlar Cone
  • Surround Material Rubber
  • Voice Coil Wire Material Copper
  • Voice Coil Former Kapton® / Polyimide
  • Dual Voice Coil
  • Basket / Frame Material Steel
  • Magnet Material Ferrite
  • Shielded
  • Overall Outside Diameter 306 mm
  • Overall Depth 153 mm
  • Baffle Cutout Diameter 275 mm
  • Bolt Circle Diameter
  • # Mounting Holes 8
  • Mounting Hole Diameter
  • Sealed Volume 1.14 ft.³
  • Sealed F3 48 Hz
  • Vented Volume 3.42 ft.³
  • Vented F3 26 Hz
