Dayton Audio DC200-8 8" Classic Woofer

€ 48,25 6 Auf Lager: Lieferzeit 1-3 Werktage
The Dayton Audio DC200-8 Classic Series 8" woofer achieves high levels of performance at a reasonable price. It's perfect as the basis of a custom speaker project, or for repairs and upgrades.... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €45,84 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

The Dayton Audio DC200-8 Classic Series 8" woofer achieves high levels of performance at a reasonable price. It's perfect as the basis of a custom speaker project, or for repairs and upgrades.



Highlights

  • Great price/performance ratio
  • Treated non-pressed paper cone with rubber surround
  • Vented pole piece for better power handling
  • Clean, balanced sound quality



Product details

Dayton Audio DC200-8 8" Classic Woofer



Dayton Audio's DC200-8 Classic Series 8" woofer offers one of the best price/performance values available anywhere. This DC200-8 8" speaker, and in fact the whole Classic Series, has a non-pressed treated paper cone, ASV voice coil, vented pole piece, rubber surround, coated cloth dust cap, and excellent low frequency performance.



Eigenschaften

Artikelnummer:
DC200-8
Woofer Series
Classic Series
Woofer Type
Midwoofer
Nominal Diameter
8"
Power Handling (RMS)
60 watts
Power Handling (max)
120 watts
Impedance
8 ohms
Sensitivity
87 dB @ 2.83V/1m
Frequency Response
29 - 3,000 Hz
Voice Coil Diameter
35 mm
Magnet Weight
15 oz
DC Resistance (Re)
6.41 ohms
Voice Coil Inductance (Le)
2.32 mH @ 1 kHz
Resonant Frequency (Fs)
30.3 Hz
Mechanical Q (Qms)
3.06
Electromagnetic Q (Qes)
0.49
Total Q (Qts)
0.42
Diaphragm Mass Inc. Airload (Mms)
36.1g
Mechanical Compliance of Suspension (Cms)
0.77 mm/N
Surface Area of Cone (Sd)
211.2 cm²
Volume of Displacement (Vd)
95.1 cm³
BL Product (BL)
9.5 Tm
Compliance Equivalent Volume (Vas)
45.7 liters
Maximum Linear Excursion (Xmax)
4.5 mm
Cone / Diaphragm Material
Treated Paper
Surround Material
Rubber
Voice Coil Wire Material
Copper
Voice Coil Former
Aluminum
Basket / Frame Material
Steel
Magnet Material
Ferrite
Overall Outside Diameter
205 mm
Overall Depth
93.5 mm
Baffle Cutout Diameter
183 mm
# Mounting Holes
4
Sealed Volume
0.46 ft.³
Sealed F3
66 Hz
Vented Volume
1.36 ft.³
Vented F3
37 Hz
