Dayton Audio CE38MB-32 1-1/2" Mini Speaker Black

Lieferzeit: 1-3 Werktage

  • Artikelnummer: CE38MB-32
  • Vorrat: 8 Auf Lager

The CE38MB-32 from Dayton Audio is a versatile mini speaker with a black Mylar diaphragm and a 32 ohm impedance, which makes it a great replacement driver for headphones. Features a lightweight and powerful neodymium magnet, and a steel frame.

€ 4,25 Inkl. MwSt.

  • 4 für je €4,04 kaufen und 5% sparen Sale 5%

Zur Wunschliste hinzufügen

  • Gratis DHL-Versand ab 149€ (DE, A) Tooltip

    Bestellungen an Werktagen vor 16Uhr werden noch am selben Tag versandt. Weitere Informationen

  • Versand am selben Tag
  • 45 Tage Bedenkzeit
  • Zahlung mit Paypal/Kreditkarte

Produktbeschreibung

Dayton Audio CE38MB-32 1-1/2" Mini Speaker Black

The CE38MB-32 from Dayton Audio is a versatile mini speaker with a black Mylar diaphragm and a 32 ohm impedance, which makes it a great replacement driver for headphones. Features a lightweight and powerful neodymium magnet, and a steel frame.



Highlights

  • Lightweight mylar diaphragm
  • Rugged steel frame with front gasket
  • Powerful neodymium magnet
  • Suitable for headphone applications
  • 32 ohm impedance



Product details

Dayton Audio CE Series CE38MB-32 1-1/2" Mini Speaker Black 32 Ohm

The Commercial Engineering (CE) Series drivers from Dayton Audio provides engineers, designers, and integrators with a line of economical small drivers that fit the diverse range of applications found in consumer electronics and audio-enabled electronic projects.

Featuring a smooth-sounding and feather-light Mylar diaphragm and high 32 ohm impedance, the CE38MB-32 driver is the perfect replacement driver for headphones. The 32 ohm impedance makes it an easy load for the integrated headphone amplifier in most portable music devices and phones, while the 38mm frame replaces most 40 mm nominal size headphone drivers. It’s also a great fit for other low-power mini speaker applications, such as electronic toys, speakerphones, and intercoms.



Note: The Mylar diaphragm is very fragile. To prevent damage, avoid contact with the diaphragm when handling. This driver should be installed behind a grille.

Eigenschaften

Spezifikationen für: CE38MB-32 1-1/2" Mini Speaker Black

  • Woofer Series Spezielle Woofer- Produktionsreihe des Herstellers. CE Series
  • Woofer Type Art des Drivers, wie zum Beispiel, Subwoofer, Midwoofer, Full-range, Coaxial-Woofer Full-range
  • Nominal Diameter Ungefährer Durchmesser des Drivers, gemessen in Inch. 1-1/2"
  • Power Handling (RMS) Durchschnittliche elektrische Bestlastbarkeit eines Lautsprechers in Watt, ohne den Driver zu beschädigen. RMS = Root Mean Square steht für Root Mean Square. 0.25 Watts
  • Power Handling (max) Die maximale kurzzeitige elektrische Belastbarkeit eines Lautsprechers in Watt, bevor es zu Schäden kommt. 0.50 Watts
  • View all specifications
  • Continuous Program Power
  • Impedance 32 ohms
  • Sensitivity 78 dB 1W/1m
  • Frequency Response 137 to 20,000 Hz
  • Voice Coil Diameter 0.5"
  • Magnet Weight
  • DC Resistance (Re) 31.98 ohms
  • Voice Coil Inductance (Le) 1.31 mH
  • Resonant Frequency (Fs) 137.9 Hz
  • Mechanical Q (Qms) 0.66
  • Electromagnetic Q (Qes) 1.15
  • Total Q (Qts) 0.42
  • Diaphragm Mass Inc. Airload (Mms) 0.06g
  • Moving Mass Of Diaphragm (Mmd)
  • Mechanical Compliance of Suspension (Cms) 21.3 mm/N
  • Surface Area of Cone (Sd) 4.9 cm²
  • Volume of Displacement (Vd)
  • BL Product (BL) 1.32 Tm
  • Compliance Equivalent Volume (Vas)
  • Maximum Linear Excursion (Xmax) 0.1 mm
  • Driver's Mechanical Losses (Rms)
  • Cone / Diaphragm Material Poly / Mylar Diaphragm
  • Surround Material
  • Voice Coil Wire Material
  • Voice Coil Former
  • Dual Voice Coil
  • Basket / Frame Material Steel
  • Magnet Material Neodymium
  • Shielded
  • Overall Outside Diameter 1.57"
  • Overall Depth 0.22"
  • Baffle Cutout Diameter 1.4"
  • Bolt Circle Diameter
  • # Mounting Holes
  • Mounting Hole Diameter
  • Sealed Volume
  • Sealed F3
  • Vented Volume
  • Vented F3
