- Artikelnummer:
- BG 17
- Woofer Type
- Full-Range
- Nominal Diameter
- 6.5"
- Power Handling (RMS)
- 40 Watts
- Power Handling (max)
- 60 Watts
- Impedance
- 8 ohms
- Sensitivity
- 93 dB (1 W/1 m)
- Frequency Response
- 80–20,000 Hz
- Voice Coil Diameter
- 20 mm
- DC Resistance (Re)
- 6.3 ohm
- Voice Coil Inductance (Le)
- 0.7 mH
- Resonant Frequency (Fs)
- 120 Hz
- Mechanical Q (Qms)
- 2.94
- Electromagnetic Q (Qes)
- 0.98
- Total Q (Qts)
- 0.74
- Diaphragm Mass Inc. Airload (Mms)
- 6.5 g
- Compliance Equivalent Volume (Vas)
- 8.2 L
- Maximum Linear Excursion (Xmax)
- 1.5 mm
- Magnet Material
- Ferrite
- Overall Outside Diameter
- 165 mm
- Overall Depth
- 61.5 mm
- Baffle Cutout Diameter
- 146 mm
- Bolt Circle Diameter
- 155 mm
- # Mounting Holes
- 4
- Mounting Hole Diameter
- 4.8 mm
