      CD-2514Fe/PT Kompressionstreiber

      Beyma CD-2514Fe/PT Kompressionstreiber

      €179,95

      2 Auf Lager

      Zum Warenkorb hinzufügen

      Beyma CD-2514Fe/PT Kompressionstreiber

      0 reviews
      0 von 5
      0 reviews
      5 Sterne
      0%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      0%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      Marke: Beyma
      Zeige alle Neue Produkte
      1.4" | 8 Ω
      CD-2514Fe/PT Kompressionstreiber
      CD-2514Fe/PT Kompressionstreiber
      CD-2514Fe/PT Kompressionstreiber
      CD-2514Fe/PT Kompressionstreiber
      148,72 €179,95 € 2 Auf Lager
      • -5% Bestelle 4 für nur 170,95 € je Stück
      +-
      Zum Warenkorb hinzufügen

      Buy now, pay later

      • Kostenloser Versand (DE & A)
      • Jetzt bestellt, morgen versandt
      • Mindestens zwei Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      Haben Sie eine Frage zu diesem Produkt?

      Haben Sie eine Frage zu diesem Produkt?

      Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

      CD-2514Fe/PT Kompressionstreiber
      CD-2514Fe/PT Kompressionstreiber
      CD-2514Fe/PT Kompressionstreiber
      CD-2514Fe/PT Kompressionstreiber

      Vor-und Nachteile

      Laut unserer Spezialisten
      • Deplocex® Patent Pending Technology for improved thermal disipation, low power compression losses and high power handling

      Produktbeschreibung Beyma CD-2514Fe/PT Kompressionstreiber

      The Beyma CD-2514Fe-PT is a high-performance 1.4" exit compression driver engineered for clarity, high output, and efficient thermal performance in demanding audio systems. Designed with Beyma’s Deplocex® thermal technology and a ceramic magnetic circuit, this driver excels in professional loudspeaker applications where power and fidelity are essential.



      Highlights of the Beyma CD-2514Fe-PT

      • 1.4” throat exit with a 2.5” copper-clad aluminum voice coil on a Nomex former
      • Delivers 200 W program power above 1.2 kHz with 108.5 dB sensitivity
      • FEM-optimized polyester dome and ceramic magnetic circuit for extended, linear response
      • Deplocex® technology enhances heat dissipation and minimizes power compression losses



      Product details Beyma CD-2514Fe-PT

      Beyma CD-2514Fe-PT Compression Driver



      The Beyma CD-2514Fe-PT is a compact yet powerful 1.4” compression driver ideal for high-efficiency loudspeaker designs. It features a 2.5” voice coil made from copper-clad aluminum wire wound on a Nomex former, ensuring reliable thermal and mechanical performance. Rated at 200 W program power above 1.2 kHz, it delivers consistent high output with a remarkable 108.5 dB sensitivity (1W/1m). The driver is built around Beyma’s proprietary Deplocex® patent-pending technology, which improves thermal dissipation and reduces power compression, making it well-suited for demanding PA and professional audio applications. The acoustic design includes an advanced polyester diaphragm and surround optimized via FEM analysis to provide extended frequency response from 0.6 to 20 kHz with minimal distortion. A copper shorting cap ensures lower harmonic distortion and a more linear inductive behavior. The ceramic-based FEM-optimized magnetic assembly produces a strong and efficient flux density of 1.6 T, contributing to the driver’s accurate transient response and clean sound reproduction. Physically, the CD-2514Fe-PT has a 145 mm diameter and a depth of 62.7 mm. It mounts using four M6 threaded holes on a standard 101.6 mm (4 in) circle. Weighing only 3.5 kg, this driver strikes a balance between weight and durability, making it an excellent fit for fixed installations or portable sound systems.

      Mehr anzeigen

      Eigenschaften

      Artikelnummer:
      CD-2514Fe/PT
      EAN
      8435469051423
      Hochtönertyp
      Compression Driver
      Cone / Dome Diameter
      2.5"
      Belastbarkeit (QMW)
      200 Watts
      Impedanz (Z)
      8 Ω
      Außendurchmesser
      145 mm
      Tiefe
      62.7 mm

      Mehr anzeigen
