      CD-171Fe/PT Kompressionstreiber

      Beyma CD-171Fe/PT Kompressionstreiber

      €92,45

      5 Auf Lager

      Zum Warenkorb hinzufügen

      Beyma CD-171Fe/PT Kompressionstreiber

      1 reviews
      5 von 5
      1 reviews
      5 Sterne
      100%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      0%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      Marke: Beyma
      Zeige alle Neue Produkte
      1" | 8 Ω
      CD-171Fe/PT Kompressionstreiber
      CD-171Fe/PT Kompressionstreiber
      CD-171Fe/PT Kompressionstreiber
      CD-171Fe/PT Kompressionstreiber
      76,41 €92,45 € 5 Auf Lager
      • -5% Bestelle 4 für nur 87,83 € je Stück
      +-
      Zum Warenkorb hinzufügen

      Buy now, pay later

      • Wir versenden nach
      • Jetzt bestellt, morgen versandt
      • Mindestens zwei Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      Haben Sie eine Frage zu diesem Produkt?

      Haben Sie eine Frage zu diesem Produkt?

      Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

      CD-171Fe/PT Kompressionstreiber
      CD-171Fe/PT Kompressionstreiber
      CD-171Fe/PT Kompressionstreiber
      CD-171Fe/PT Kompressionstreiber

      Produktbeschreibung Beyma CD-171Fe/PT Kompressionstreiber

      The Beyma CD-171Fe-PT is a powerful and efficient 1” exit compression driver designed for high-frequency precision and durability. Built with Deplocex® thermal technology, a robust ceramic magnet, and FEM-optimized components, this driver is ideal for high-performance PA systems and professional audio installations.



      Highlights of the Beyma CD-171Fe-PT

      • 1” throat exit with a 1.75” copper-clad aluminum voice coil on a Kapton former
      • Delivers 160 W program power above 1.2 kHz with 108 dB sensitivity
      • FEM-optimized polyester diaphragm and ceramic magnet for extended, controlled response
      • Deplocex® technology for superior thermal dissipation and reduced power compression



      Product details Beyma CD-171Fe-PT

      Beyma CD-171Fe-PT Compression Driver



      The Beyma CD-171Fe-PT is a next-generation 1” high-frequency compression driver designed for accuracy, reliability, and thermal efficiency. Featuring a 1.75” voice coil made of copper-clad aluminum wound on a Kapton former, it supports up to 160 W of program power above 1.2 kHz. The driver maintains high output with a sensitivity of 108 dB (1W/1m), ensuring powerful and articulate sound reproduction. Equipped with Deplocex® patent-pending thermal dissipation technology, the CD-171Fe-PT minimizes power compression while delivering consistent output during demanding use. The diaphragm is made of advanced polyester with FEM-optimized geometry, paired with a copper shorting cap to reduce distortion and enhance linearity. Its ceramic magnetic circuit, also FEM-optimized, delivers 1.6 T of flux density with a Bl factor of 5.4 N/A, providing excellent transient response and sound control over a frequency range of 0.8 to 20 kHz. This compression driver is compact and easy to integrate, with an overall diameter of 120 mm and a depth of 59 mm. Mounting is versatile, featuring three M5 threaded holes (120º apart on a 57 mm circle) and two M5 holes (180º apart on a 76.2 mm circle). Weighing just 2.3 kg, the CD-171Fe-PT is suitable for both fixed installations and touring audio systems where space and weight are important factors.

      Mehr anzeigen

      Eigenschaften

      Artikelnummer:
      CD-171Fe/PT
      EAN
      8435469051584
      Hochtönertyp
      Compression Driver
      Cone / Dome Diameter
      1.1"
      Belastbarkeit (QMW)
      160 Watts
      Impedanz (Z)
      8 Ω
      Gleichstromwiderstand (Re)
      6 Ω
      Außendurchmesser
      90.4 mm
      Tiefe
      44 mm

      Mehr anzeigen

      Bewertungen

      1 reviews
      Produkt bewerten
      5 von 5
      -
      Durch Xaver on 13 Dezember 2025
      CD-171Fe/PT Kompressionstreiber
      76,41 €
      92,45 €
