      CD-101Fe/PT Kompressionstreiber

      Beyma CD-101Fe/PT Kompressionstreiber

      €74,95

      4 Auf Lager

      Zum Warenkorb hinzufügen

      Beyma CD-101Fe/PT Kompressionstreiber

      0 reviews
      0 von 5
      0 reviews
      5 Sterne
      0%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      0%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      Marke: Beyma
      Zeige alle Neue Produkte
      1" | 8 Ω
      CD-101Fe/PT Kompressionstreiber
      CD-101Fe/PT Kompressionstreiber
      CD-101Fe/PT Kompressionstreiber
      CD-101Fe/PT Kompressionstreiber
      61,94 €74,95 € 4 Auf Lager
      • -5% Bestelle 4 für nur 71,20 € je Stück
      +-
      Zum Warenkorb hinzufügen

      Buy now, pay later

      • Wir versenden nach
      • Jetzt bestellt, morgen versandt
      • Mindestens zwei Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      Haben Sie eine Frage zu diesem Produkt?

      Haben Sie eine Frage zu diesem Produkt?

      Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

      CD-101Fe/PT Kompressionstreiber
      CD-101Fe/PT Kompressionstreiber
      CD-101Fe/PT Kompressionstreiber
      CD-101Fe/PT Kompressionstreiber

      Produktbeschreibung Beyma CD-101Fe/PT Kompressionstreiber

      The Beyma CD-101Fe-PT is a compact, lightweight 1” compression driver designed for high-efficiency high-frequency reproduction. Built with Deplocex® and VPEQ® technologies, it combines excellent thermal handling with linear frequency response in a highly compact footprint, making it ideal for portable and space-constrained audio systems.



      Highlights of the Beyma CD-101Fe-PT

      • 1” throat with 1.1” copper-clad aluminum voice coil
      • Delivers 80 W program power above 2 kHz with 108 dB sensitivity
      • Deplocex® and VPEQ® technologies for improved linearity and thermal performance
      • FEM-optimized polyester diaphragm and ceramic magnetic circuit



      Product details Beyma CD-101Fe-PT

      Beyma CD-101Fe-PT Compression Driver



      The Beyma CD-101Fe-PT is a next-generation 1” exit compression driver engineered for clear, extended, and consistent high-frequency response in compact loudspeaker designs. It features a 1.1” copper-clad aluminum voice coil paired with a FEM-optimized advanced polyester annular ring diaphragm. This combination delivers an excellent transient response and reduced harmonic distortion across its wide 2 – 20 kHz frequency range. The CD-101Fe-PT is equipped with Beyma’s Deplocex® technology for enhanced thermal dissipation and reduced power compression, while the VPEQ® system ensures linearity throughout its working range. The driver handles 80 W program power and offers 108 dB sensitivity (1W/1m), making it suitable for low-power but high-clarity applications such as portable PA, nearfield monitors, and compact line arrays. Its ceramic magnet structure provides a magnetic flux density of 1.4 T and a Bl factor of 2.3 N/A, delivering efficient electromagnetic performance. The unit is extremely compact and lightweight, measuring just 90.4 mm in diameter and 55 mm in depth, and weighing only 0.5 kg. Mounting is versatile with three M5 threaded holes (120º apart on a 57 mm diameter circle) and two additional M5 holes (180º apart on a 76.2 mm circle), ensuring compatibility with a range of horns and enclosures. The CD-101Fe-PT is an excellent solution for designers needing precision and performance in a compact compression driver format.

      Mehr anzeigen

      Eigenschaften

      Artikelnummer:
      CD-101Fe/PT
      EAN
      8435469058712
      Hochtönertyp
      Compression Driver
      Cone / Dome Diameter
      1”
      Belastbarkeit (QMW)
      80 Watts
      Impedanz (Z)
      8 Ω
      Empfindlichkeit (SPL bei 1m / 2,83V)
      108 dB
      Frequenzgang
      2.000-20.000 Hz
      Gleichstromwiderstand (Re)
      6 Ω
      Außendurchmesser
      90.4 mm
      Ausschnittdurchmesser
      72 mm
      Tiefe
      55 mm
      Bestätigungstyp
      3 Screws. 5.00 mm

      Mehr anzeigen
