      C51-6-286 2'' Ceramic Cell Hochtöner

      C51-6-286 2'' Ceramic Cell Hochtöner

      €679,95

      Accuton C51-6-286 2'' Ceramic Cell Hochtöner

      0 reviews
      0 von 5
      0 reviews
      5 Sterne
      0%
      4 Sterne
      0%
      3 Sterne
      0%
      2 Sterne
      0%
      1 Stern
      0%
      Alle Bewertungen anzeigen
      Marke: Accuton
      561,94 €679,95 € 4 Auf Lager10+ erwartet auf 28-06-2024

      Buy now, pay later

      • Kostenloser Versand (DE & A)
      • Vor 16:00 Uhr bestellt, heute versandt
      • Mindestens zwei Jahre Garantie
      • 45 Tage Widerrufsrecht
      • Kundenbewertung:
      Angebot anfordern
      Haben Sie eine Frage zu diesem Produkt?

      Haben Sie eine Frage zu diesem Produkt?

      Unser Mitarbeiter hilft Ihnen gerne, das richtige Produkt zu finden

      Vor-und Nachteile

      Laut unserer Spezialisten
      • We recommend our C51-6-286 in an application above 800 Hz

      Produktbeschreibung

      The C51-6-286 is a 2 inch tweeter with ultra hard ceramic dome in a 86 mm body. A proprietary clamping technique provides easy mounting and adapting to individual frontplates. As the dome breakup is above the audible range and well damped, no dome cutouts are required.



      Highlights

      • full featured cell concept
      • underhung motor design
      • vented vc & pole piece
      • no ferrofluid filling
      • 800 HZ - 10000 HZ



      Product details



      Accuton C51-6-286 2'' Ceramic Cell Tweeter



      A unique FEA optimized underhung motor design with vented titanium voice coil former and double neodymium magnet guarantees low energy storage, excellent heat transfer and high excursion capability for low power compression and ultra low distortion. The new designed soft fabric surround centers the moving parts with improved linearity. We recommend the C51-6-286 in an application above 800 Hz.



      The ultra-hard ceramic dome is made of a material that is extremely stiff and light, which makes it ideal for high-frequency reproduction. The ceramic material used in the dome is also highly resistant to temperature changes and humidity, which makes it ideal for use in high-end audio systems

      Mehr anzeigen

      Eigenschaften

      Artikelnummer:
      C51-6-286
      Hochtöner-Serie
      Ceramic Cell Tweeter
      Belastbarkeit (QMW)
      120 Watt
      Impedanz (Z)
      8 Ohm
      Empfindlichkeit (SPL bei 1m / 2,83V)
      93 dB
      Frequenzgang
      800 - 10.000 Hz
      Resonanzfrequenz (Fs)
      581 Hz
      Gleichstromwiderstand (Re)
      5.6 Ohm
      Mechanische Güte (Qms)
      4.86
      Electromagnetic Q (Qes)
      1.61
      Gesamtgüte (Qts)
      1.21
      Außendurchmesser
      85.6 mm
      Ausschnittdurchmesser
      86 mm
      Tiefe
      87 mm

      Mehr anzeigen
