Dayton Audio LS12-44 12" Low Profile Subwoofer Dual 4 Ohm

€ 148,25 Nicht auf Lager: Lieferzeit beträgt 1 Woche
At a depth of less than 4", Dayton Audio's LS12-44 12" low profile subwoofer fits into shallow spaces that ordinary subs wouldn't dream of attempting! Dual 2" 4 ohm coils provide flexible wiring, while the flat cone and innovative suspension support 10 mm... Mehr anzeigen
Bulk discount Genießen Sie diese tollen Rabattangebote
  • -5% Kauf 4 für nur €140,84 pro stück
  • Versicherter Versand mit Sendungsverfolgung
  • Kostenloser Versand ab 149€ (DE, A)
  • Versand am selben Tag*
  • Hausinterner technischer Support

Produktbeschreibung

At a depth of less than 4", Dayton Audio's LS12-44 12" low profile subwoofer fits into shallow spaces that ordinary subs wouldn't dream of attempting! Dual 2" 4 ohm coils provide flexible wiring, while the flat cone and innovative suspension support 10 mm of Xmax!



Highlights

  • Innovative low-profile subwoofer -- less than 4" thick!
  • 10 mm Xmax for uncompromised bass performance
  • Dual 4 ohm voice coils, 6 layers total, for high BL force and multiple wiring options
  • Rigid flat honeycomb fiberglass cone maintains its integrity under severe conditions
  • Low distortion ferrite motor with dual aluminum shorting rings keeps the bass clean and powerful
  • Balanced rubber double-roll surround design improves stability and control



Product details

Dayton Audio LS12-44 12" Low Profile Subwoofer Dual 4 Ohm



Back with a new and improved design, Dayton Audio's shallow subwoofers let you put more bass into less space! The new LS12-44 Low Profile Subwoofer from Dayton Audio provides over 10 mm of controlled excursion, for bass that hits hard and goes deep -- even in places ordinary subwoofers just won't fit! These drivers are perfect for installation in walls, floors, and ceilings, or in limited-clearance automotive applications like the narrow space behind pickup truck seats. They might even fit under your chair or behind your sofa!



Innovative design makes the shallow form factor of the LS Series low profile subwoofers possible. A flat, rigid piston made of aluminum honeycomb with glass fiber skins replaces the conventional cone of most subwoofers, and a balanced double-roll surround design maximizes the stability of the moving structure, even at high excursion, preventing mechanical noise. The motor assembly is optimized for symmetrical motion and low distortion, featuring dual heavy-gauge aluminum shorting rings for low inductance and fast, impactful bass. Lastly, a 6-layer dual voice coil ensures maximum available force from the compact motor, which features high-grade ceramic ferrite magnetic material, and enables 2 ohm or 8 ohm wiring.



Nothing has been sacrificed in creating these truly next-generation shallow subwoofers, capable of over 10 mm of linear excursion form an ultra-slim package. Trust the LS Series subwoofer drivers to deliver years of rugged, long-lasting enjoyment, wherever you install them. Wherever you would like to add more bass, Dayton Audio has you covered.



Note: All parameters derived with voice coils wired in series.



Eigenschaften

Artikelnummer:
LS12-44
Woofer Series
Low Profile Series
Woofer Type
Subwoofer
Nominal Diameter
12"
Power Handling (RMS)
250 watts
Power Handling (max)
500 watts
Impedance
4+4 ohms
Sensitivity
88 dB @ 2.83V/1m
Frequency Response
28 - 300 Hz
Voice Coil Diameter
50 mm
DC Resistance (Re)
7.5 ohms
Voice Coil Inductance (Le)
5.34 mH @ 1 kHz
Resonant Frequency (Fs)
33.7 Hz
Mechanical Q (Qms)
4.95
Electromagnetic Q (Qes)
0.56
Total Q (Qts)
0.51
Diaphragm Mass Inc. Airload (Mms)
166g
Mechanical Compliance of Suspension (Cms)
0.13 mm/N
Surface Area of Cone (Sd)
547.3 cm²
Volume of Displacement (Vd)
54.7 cm³
BL Product (BL)
21.7 Tm
Compliance Equivalent Volume (Vas)
56.6 liters
Maximum Linear Excursion (Xmax)
10 mm
Cone / Diaphragm Material
Fiberglass Cone
Surround Material
Rubber
Basket / Frame Material
Cast Alumnium
Magnet Material
Ferrite
Overall Outside Diameter
315 mm
Overall Depth
98.5 mm
Baffle Cutout Diameter
282 mm
# Mounting Holes
8
