- Artikelnummer
- M6N
- Woofer Type
- Midwoofer
- Nominal Diameter
- 6"
- Power Handling (RMS)
- 45 Watts
- Power Handling (max)
- 90 Watts
- Impedance
- 8 ohms
- Sensitivity
- 89 dB 2.83V/1m
- Frequency Response
- 46 to 8,000 Hz
- Voice Coil Diameter
- 1"
- DC Resistance (Re)
- 6.5 ohms
- Resonant Frequency (Fs)
- 46 Hz
- Mechanical Q (Qms)
- 4.69
- Electromagnetic Q (Qes)
- 0.42
- Total Q (Qts)
- 0.39
- Diaphragm Mass Inc. Airload (Mms)
- 13.6g
- Mechanical Compliance of Suspension (Cms)
- 0.871 mm/N
- Surface Area of Cone (Sd)
- 133 cm²
- Compliance Equivalent Volume (Vas)
- 0.77 ft.³
- Maximum Linear Excursion (Xmax)
- 4.3 mm
- Cone / Diaphragm Material
- Aluminium / Magnesium
- Surround Material
- Rubber
- Voice Coil Former
- Kapton® / Polyimide
- Dual Voice Coil
- No
- Basket / Frame Material
- Steel
- Magnet Material
- Ferrite
- Shielded
- Yes
- Overall Outside Diameter
- 7"
- Overall Depth
- 4.0625"
- Baffle Cutout Diameter
- 5.313"
- # Mounting Holes
- 4
- Sealed Volume
- 0.23 ft.³
- Sealed F3
- 87 Hz
- Vented Volume
- 0.72 ft.³
- Vented F3
- 46 Hz
