    Visaton R 10 S - 4 4" Full-Range Speaker 4 Ohm

    € 8,95 4 Op voorraad: levertijd 1 werkdag
    10 cm (4") full-range speaker offers great frequency response and sensitivity in a compact package. Great for point-source applications with a limited amount of mounting depth space.... Toon meer
    Volume voordeel Geniet van deze geweldige kortingsdeals
    • -5% Bestel 4 voor slechts €8,50 per stuk
    • Verzending altijd verzekerd en met track & trace
    • Voor 16u besteld, vandaag verstuurd*
    • Gratis verzending vanaf €99
    • In-house technische support

    Productomschrijving

    10 cm (4") fullrange speaker offers great frequency response and sensitivity in a compact package. Great for point-source applications with a limited amount of mounting depth space.



    Highlights

    • Full-range frequency response from 100 to 13,000 Hz
    • Thin mount profile with a mounting depth of 36 millimeters
    • High 90 dB sensitivity



    Product details

    Visaton R 10 S 4" Full-Range Speaker 4 Ohm



    Designed or electronic devices, and to be used in the ceiling structures of rail cars and buses, Visaton's R 10 S full-range speaker has very linear response from 150 to 10,000 Hz. The slim design features a depth of 36 millimeters for shallow mounting. High sensitivity and good power handling combine for more output than many midrange drivers this size, while the paper cone and accordion surround create a more natural, classic sound that is pleasing to most peoples' ears. A square steel mounting plate eliminates the need for a baffle recess, while the mounting slots can accept a wider range of mounting diameters.

    Specificaties

    Artikelnummer
    R 10 S - 4
    Woofer Series
    R Series
    Woofer Type
    Full-Range
    Nominal Diameter
    4"
    Power Handling (RMS)
    20 Watts
    Power Handling (max)
    30 Watts
    Impedance
    4 ohms
    Sensitivity
    90 dB (1 W/1 m)
    Frequency Response
    100 - 13,000 Hz
    Voice Coil Diameter
    15 mm
    DC Resistance (Re)
    3.4 ohms
    Voice Coil Inductance (Le)
    0.2 mH
    Resonant Frequency (Fs)
    160 Hz
    Mechanical Q (Qms)
    5.53
    Electromagnetic Q (Qes)
    1.96
    Total Q (Qts)
    1.45
    Diaphragm Mass Inc. Airload (Mms)
    1.9g
    Surface Area of Cone (Sd)
    56 cm2
    BL Product (BL)
    1.9 Tm
    Compliance Equivalent Volume (Vas)
    1.9 liters
    Maximum Linear Excursion (Xmax)
    0.5 mm
    Cone / Diaphragm Material
    Paper
    Surround Material
    Treated Paper
    Basket / Frame Material
    Steel
    Magnet Material
    Ferrite
    Overall Outside Diameter
    94 mm
    Overall Depth
    36 mm
    Baffle Cutout Diameter
    93 mm
    Bolt Circle Diameter
    117 mm
    # Mounting Holes
    4
    Mounting Hole Diameter
    5 mm
